Wet sump with replaceable oil filter on external sump
Clutch
Multidisc in oil bath
Fuel System
28 copy (original PE 28 Khehin with Daytona Anima engine)
Transmission
DID 420 B&B chain
Final: 420 pitch pinion and crown
Handlebar
Diam.28low fold in black anodized aluminum with Neken guard
Fork
UPSD MASELLI diam.38 with new setting in compression and rebound anodized gold length 720mm with pin in axis
Chassis and Suspension
Frame
High strength trellis frame and subframe with engine support box and linkage.
Tyres
Wheels / Rim
F: 12x2.50 black alloy wheels
R: 12x3.00 black colored alloy wheels
Front Tyre
100/90-12
Rear Tyre
120/80-12
Dimensions
Seat Height
810 mm
Wheelbase
1190 mm
Additional Details
Swingarm: In extruded 7020 aluminum with new exclusive Bucci design with linkage attachments and roller cages
Rear shock absorber: MASELLI with rooster colored spring and body completely machined from solid with variable distance between centers, 16mm chromed piston rod 46 with 2 adjustments.
Air filter: DT1 in sponge
