The Trek Emonda SLR 9 AXS redefines ultralight precision with its 800 Series OCLV Carbon frame and SRAM RED eTap AXS wireless drivetrain. Weighing only 6.75 kg, it’s engineered for serious climbers who crave power without compromise. Seamless integration and carbon everything make it fast, focused, and fiercely responsive.
Not Available
Book a Test Drive through Bikes4Sale and we will try to get you the best offer for Trek Emonda SLR 9 AXS.
| Vehicle Type | Bicycle |
| Handlebar | Bontrager Aeolus RSL Integrated bar/stem |
| Fork | Emonda SLR full carbon, tapered carbon steerer, internal brake routing, flat mount disc, 12x100mm thru axle |
| Seatpost | Size: 47, 50, 52, 54 Bontrager carbon seatmast cap, 20mm offset, short length Size: 56, 58, 60, 62 Bontrager carbon seatmast cap, 20mm offset, tall length |
| Grip | Bontrager Supertack Perf tape |
| Crankset | Size: 47 SRAM RED AXS w/ power meter, 48/35, DUB, 165mm length Size: 50, 52 SRAM RED AXS, power meter, 48/35, DUB, 170mm length Size: 54, 56, 58 SRAM RED AXS, power meter, 48/35, DUB, 172.5mm length Size: 60, 62 SRAM RED AXS, power meter, 48/35, DUB, 175mm length |
| Chain | SRAM RED D1, 12 speed |
| Shifters | SRAM RED eTap AXS, 12 speed |
| Saddle | Size: 47, 50, 52, 54, 56, 58, 60, 62 Bontrager Aeolus Pro, carbon rails, 145mm width Size: 47, 50, 52 Aeolus RSL, carbon rails, 155mm width Size: 47, 50, 52 Bontrager Aeolus P2 Pro, carbon rails, 155mm width Size: 54, 56, 58, 60, 62 Aeolus RSL, carbon rails, 145mm width |
| Derailleur : Front | SRAM RED eTap AXS, braze-on |
| Derailleur : Rear | SRAM RED eTap AXS, 36T max cog |
| Cassette | SRAM XG-1290, 10-33, 12 speed |
| Chainrings | 1x: 50T, 2x: 53/39 |
| Bottom Bracket | SRAM DUB, T47 threaded, internal bearing |
| Electricals | |
|---|---|
| Battery | SRAM AXS battery pack (with charger) |
| Brakes | |
|---|---|
| Front Brake | SRAM Red AXS hydraulic disc, flat mount SRAM CenterLine X, centerlock, round edge, 160mm |
| Rear Brake | SRAM Red AXS hydraulic disc, flat mount SRAM CenterLine X, centerlock, round edge, 160mm |
| Chassis and Suspension | |
|---|---|
| Frame | Ultralight 800 Series OCLV Carbon, Ride Tuned performance tube optimization, tapered head tube, internal routing, DuoTrap S compatible, flat mount disc, 142x12mm thru axle |
| Tyres | |
|---|---|
| Wheels / Rim | Front: Bontrager Aeolus RSL 37, OCLV Carbon, Tubeless Ready, 37mm rim depth, 100x12mm thru axle Rear: Bontrager Aeolus RSL 37, OCLV Carbon, Tubeless Ready, 37mm rim depth, 142x12mm thru axle |
| Front Tyre | Size: 47, 50, 52, 54, 56, 58, 60, 62 Pirelli P Zero Race, 127 tpi, 700x26mm Size: 47, 50, 52, 54, 56, 58, 60, 62 Bontrager R3 Hard-Case Lite, aramid bead, 120 tpi, 700x25mm Size: 47, 50, 52, 54, 56, 58, 60, 62 Bontrager R4 320, 700x25mm Size: 47, 50, 52, 54, 56, 58, 60, 62 Pirelli P Zero Race, 120 tpi, tubeless compatible, 700x26mm |
| Rear Tyre | Size: 47, 50, 52, 54, 56, 58, 60, 62 Pirelli P Zero Race, 127 tpi, 700x26mm Size: 47, 50, 52, 54, 56, 58, 60, 62 Bontrager R3 Hard-Case Lite, aramid bead, 120 tpi, 700x25mm Size: 47, 50, 52, 54, 56, 58, 60, 62 Bontrager R4 320, 700x25mm Size: 47, 50, 52, 54, 56, 58, 60, 62 Pirelli P Zero Race, 120 tpi, tubeless compatible, 700x26mm |
| Dimensions | |
|---|---|
| Weight | 6.75 kg |
