| Vehicle Type | Bicycle |
| Load Carrying Capacity | 125 kg |
| Handlebar | Size: XS
Trek Aero RSL Road integrated bar/stem, OCLV Carbon, Race Fit, 80mm reach, 124mm drop, 35cm control width, 38cm drop width, 80mm stem length
Size: S
Trek Aero RSL Road integrated bar/stem, OCLV Carbon, Race Fit, 80mm reach, 124mm drop, 37cm control width, 40cm drop width, 90mm stem length
Size: M
Trek Aero RSL Road integrated bar/stem, OCLV Carbon, Race Fit, 80mm reach, 124mm drop, 39cm control width, 42cm drop width, 90mm stem length |
| Fork | Madone Gen 8 full carbon, tapered carbon steerer, internal brake routing, flat mount disc, 12x100mm chamfered thru axle |
| Seatpost | Size: XS, S, M
Madone aero carbon seatpost, 0mm offset, short length
Size: ML, L, XL
Madone aero carbon seatpost, 0mm offset, long length |
| Crankset | Size: XS, S
Shimano Ultegra R8100, 52/36, 165mm length
Size: M
Shimano Ultegra R8100, 52/36, 170mm length
Size: ML, L
Shimano Ultegra R8100, 52/36, 172.5mm length
Size: XL
Shimano Ultegra R8100, 52/36, 175mm length |
| Chain | Shimano Ultegra/XT M8100, 12 speed |
| Shifters | Shimano Ultegra R8170 Di2, 12 speed |
| Saddle | Size: XS, S
Bontrager Aeolus P2 Pro, carbon rails, 155mm width
Size: M, ML, L, XL
Bontrager Aeolus Pro, carbon rails, 145mm width |
| Cassette | Shimano Ultegra R8101, 11-30, 12 speed |
| Chainrings | 1x: 54T, 2x: 56/43 Max chainring size |
| Bottom Bracket | Praxis, T47 threaded, internal bearing |
| Chassis and Suspension |
|---|
| Frame | 900 Series OCLV Carbon, Full System Foil tube shaping, IsoFlow seat tube, RCS Headset System, electronic-only routing, removable aero chainkeeper, T47 BB, flat mount disc, UDH, 142x12mm thru axle |
| Front Suspension | Shimano Ultegra R8150 Di2, braze-on, down swing |
| Rear Suspension | Shimano Ultegra R8150 Di2, 34T max cog |
| Tyres |
|---|
| Wheels / Rim | F: Bontrager Aeolus Pro 51, OCLV Carbon, Tubeless Ready, 100x12mm thru axle
R: Bontrager Aeolus Pro 51, OCLV Carbon, Tubeless Ready, Shimano 11/12-speed freehub, 142x12mm thru axle |
| Front Tyre | Pirelli P Zero Race, 120 tpi, tubeless compatible, 700x28mm
32mm Max tire size |
| Rear Tyre | Pirelli P Zero Race, 120 tpi, tubeless compatible, 700x28mm
32mm Max tire size |
| Additional Details |
Skewer front/rear: Bontrager Switch chamfered thru axle, removable lever
Handlebar
Size: ML, L
Trek Aero RSL Road integrated bar/stem, OCLV Carbon, Race Fit, 80mm reach, 124mm drop, 39cm control width, 42cm drop width, 100mm stem length
Size: XL
Trek Aero RSL Road integrated bar/stem, OCLV Carbon, Race Fit, 80mm reach, 124mm drop, 41cm control width, 44cm drop width, 110mm stem length |
