The given price can change depending on the colour, accessories and other features.
| Country, City | Showroom Price | On Road Price |
|---|---|---|
| United States, Alabama | $ 669 | -- |
| United States, Alaska | $ 669 | -- |
| United States, Arizona | $ 669 | -- |
| United States, Atlanta | $ 669 | -- |
| United States, Austin | $ 669 | -- |
| United States, Baltimore | $ 669 | -- |
| United States, Boston | $ 669 | -- |
| United States, Charleston | $ 669 | -- |
| United States, Charlotte | $ 669 | -- |
| United States, Chicago | $ 669 | -- |
Book a Test Drive through Bikes4Sale and we will try to get you the best offer for Trek Marlin 5.
Lithium Grey
Radioactive Red
Volt to Miami Green Fade
Azure
| Vehicle Type | Bicycle |
| Load Carrying Capacity | Combined weight of bicycle, rider, and cargo of 300 pounds (136 kg) |
| Stem | Size : XXS - Bontrager alloy, 31.8 mm, Blendr compatible, 7 degree, 35 mm length ( Size : XS - 50 mm length ) Size : S - Bontrager alloy, 31.8 mm, Blendr compatible, 7 degree, 60 mm length ( Size : M - 70 mm length ) Size : ML, L - Bontrager alloy, 31.8 mm, Blendr compatible, 7 degree, 80 mm length Size : XL, XXL - Bontrager alloy, 31.8 mm, Blendr compatible, 7 degree, 90 mm length |
| Handlebar | Size : XXS, XS - Bontrager alloy, 31.8 mm, 5 mm rise, 690 mm width Size : S, M, ML, L, XL, XXL - Bontrager alloy, 31.8 mm, 5 mm rise, 720 mm width |
| Fork | Size : XXS - SR Suntour XCM 30, coil spring, lockout, preload, 100 mm QR, 100 mm travel Size : XS - SR Suntour XCT 30, coil spring, lockout, preload, 100 mm QR, 80 mm travel Size : S, M, ML, L, XL, XXL - SR Suntour XCT 30, coil spring, lockout, preload, 100 mm QR, 100 mm travel |
| Seatpost | Size : XXS - Bontrager alloy, 31.6 mm, 12 mm offset, 300 mm length Size : XS, S, M - Bontrager alloy, 31.6 mm, 12 mm offset, 330 mm length Size : ML, L, XL, XXL - Bontrager alloy, 31.6 mm, 12 mm offset, 400 mm length |
| Grip | Bontrager XR Endurance Comp, lock-on |
| Crankset | Size : XXS - Prowheel TM-CY10, 36/22, 160 mm length Size : XS, S, M - Shimano M315, 36/22, 170 mm length Size : ML, L, XL, XXL - Shimano M315, 36/22, 175 mm length |
| Pedals | VP-536 nylon platform |
| Chain | KMC Z8.3, 8 speed |
| Shifters | Shimano Altus M315, 8 speed |
| Saddle | Bontrager Arvada, steel rails, 138 mm width |
| Headset | Semi-integrated, 1-1/8'' |
| Derailleur : Front | Shimano Altus M315, 34.9 mm clamp, top swing, dual pull |
| Derailleur : Rear | Shimano Altus M310 |
| Hub : Front | Formula DC-22, alloy, 6-bolt, Shimano 8/9/10 freehub, 135 x 5 mm QR |
| Hub : Rear | Formula DC-20, alloy, 6-bolt, 5 x 100 mm QR |
| Spoke | 14g stainless steel |
| Cassette | Shimano HG200, 12-32, 8 speed |
| Bottom Bracket | VP BC73, 73 mm, threaded cartridge |
| Brakes | |
|---|---|
| Front Brake | Size : XXS, XS, S - Tektro HD-M276 hydraulic disc, short reach lever Size : M, ML, L, XL, XXL - Tektro HD-M275 hydraulic disc |
| Rear Brake | Size : XXS, XS, S - Tektro HD-M276 hydraulic disc, short reach lever Size : M, ML, L, XL, XXL - Tektro HD-M275 hydraulic disc |
| Chassis and Suspension | |
|---|---|
| Frame | Alpha Silver Aluminum, internal routing, chainstay disc brake mount, rack and kickstand mount, 135 x 5 mm QR |
| Tyres | |
|---|---|
| Wheels / Rim | Size : XXS - Bontrager Connection, alloy, double-wall, 32-hole, 20 mm width, schrader valve Size : XS, S, M, ML, L, XL, XXL - Bontrager Connection, double-wall, 32-hole, 20 mm width, schrader valve |
| Front Tyre | Size : XXS - Bontrager XR2 Comp, wire bead, 30 tpi, 26 x 2.20'' Size : XS, S - Bontrager XR2 Comp, wire bead, 30 tpi, 27.5 x 2.20'' Size : M, ML, L, XL, XXL - Bontrager XR2 Comp, wire bead, 30 tpi, 29 x 2.20'' |
| Rear Tyre | Size : XXS - Bontrager XR2 Comp, wire bead, 30 tpi, 26 x 2.20'' Size : XS, S - Bontrager XR2 Comp, wire bead, 30 tpi, 27.5 x 2.20'' Size : M, ML, L, XL, XXL - Bontrager XR2 Comp, wire bead, 30 tpi, 29 x 2.20'' |
| Dimensions | |
|---|---|
| Weight | 13.97 kg |
