The given price can change depending on the colour, accessories and other features.
| Country, City | Showroom Price | On Road Price |
|---|---|---|
| United States, Alabama | $ 6499 | -- |
| United States, Alaska | $ 6499 | -- |
| United States, Arizona | $ 6499 | -- |
| United States, Atlanta | $ 6499 | -- |
| United States, Austin | $ 6499 | -- |
| United States, Baltimore | $ 6499 | -- |
| United States, Boston | $ 6499 | -- |
| United States, Charleston | $ 6499 | -- |
| United States, Charlotte | $ 6499 | -- |
| United States, Chicago | $ 6499 | -- |
Book a Test Drive through Bikes4Sale and we will try to get you the best offer for Trek Rail 9.7.
Raw Carbon/Volt
Gloss Purple Phaze/Matte Raw Carbon
Solid Charcoal/Radioactive Orange
Solid Charcoal to Root Beer Ano Decal
| Vehicle Type | Bicycle |
| Fuel | Electric |
| Load Carrying Capacity | Combined weight of bicycle, rider, and cargo of 300 pounds (136 kg) |
| Top Speed | 32 kmph |
| Stem | Bontrager Rhythm Comp, 31.8 mm, Knock Block, 0 degree, 60 mm length |
| Handlebar | Bontrager Comp, alloy, 31.8 mm, 15 mm rise, 780 mm width |
| Fork | RockShox Yari RC, DebonAir spring, Motion Control RC damper, e-MTB optimized, tapered steerer, 42 mm offset, Boost110, 15 mm Maxle Stealth, 160 mm travel |
| Seatpost | Size : S - Bontrager Line Dropper, 100 mm travel, internal routing, 31.6 mm, 345 mm length Size : M, L, XL - Bontrager Line Dropper, 150 mm travel, internal routing, 31.6 mm, 440 mm length |
| Grip | Bontrager XR Trail Comp, nylon lock-on |
| Crankset | SRAM X1 1000, 34T, 165 mm length |
| Pedals | VP-536 nylon platform |
| Chain | SRAM NX Eagle, 12 speed |
| Shifters | SRAM NX Eagle single-click, 12 speed |
| Saddle | Bontrager Arvada, steel rails, 138 mm width |
| Headset | Knock Block Integrated, 58-degree radius, cartridge bearing, 1-1/8'' top, 1.5'' bottom |
| Derailleur : Rear | SRAM NX Eagle |
| Hub : Rear | Bontrager alloy, sealed bearing, alloy axle, 6-bolt, Boost110, 15 mm thru axle |
| Cassette | SRAM PG-1230 Eagle, 11-50, 12 speed |
| Motor Details |
|---|
| Bosch Performance CX, magnesium motor body, 250 watt, 85 Nm, 20mph |
| Electricals | |
|---|---|
| Battery | Bosch PowerTube 625 |
| Charger | Bosch standard 4A (100-240V) charger |
| Controller | Bosch Kiox with Anti-theft solution |
| Brakes | |
|---|---|
| Front Brake | Shimano 4-piston hydrauilc disc, M6100 lever, M6120 caliper Brake Rotor : Shimano RT76, 6-bolt, 203 mm |
| Rear Brake | Shimano 4-piston hydrauilc disc, M6100 lever, M6120 caliper Brake Rotor : Shimano RT76, 6-bolt, 203 mm |
| Chassis and Suspension | |
|---|---|
| Frame | OCLV Mountain Carbon main frame, Removable Integrated Battery (RIB), tapered head tube, Knock Block, Control Freak internal routing, magnesium rocker link, Motor Armor, Mino Link, ABP, Boost148, 12 mm thru axle, 150 mm travel |
| Tyres | |
|---|---|
| Wheels / Rim | Front : Bontrager Line Comp 30, Tubeless Ready, 6-bolt, Boost110, 15 mm thru axle Rear : Bontrager Line Comp 30, Tubeless Ready, Rapid Drive 54, 6-bolt, Shimano 8/9/10 freehub, Boost148, 12 mm thru axle |
| Front Tyre | Bontrager XR5 Team Issue, Tubeless Ready, Inner Strength sidewall, aramid bead, 120 tpi, 29 x 2.60'' |
| Rear Tyre | Bontrager XR5 Team Issue, Tubeless Ready, Inner Strength sidewall, aramid bead, 120 tpi, 29 x 2.60'' |
| Dimensions | |
|---|---|
| Weight | 22.77 kg |
| Additional Details |
|---|
| Shock : RockShox Deluxe Select+, 230 x 57.5 mm |
