4-stroke flat twin engine, double overhead camshaft, one balance shaft and variable engine timing system BMW ShiftCam
Compression Ratio
12.5 : 1
Clutch
Multiplate wet clutch, hydraulically operated
Fuel System
Electronic fuel injection with ride-by-wire throttle system
Cooling System
Air/liquid-cooling
Maximum Power
138 Ps @ 7750 Rpm
Maximum Torque
143 Nm @ 6250 Rpm
Top Speed
201kmph
Electricals
Battery
12 V / 12 Ah, maintenance-free
Brakes
Front Brake
Dual floating disc brakes, 4-piston radial calipers, diameter 320 mm
Rear Brake
Single disc brake, diameter 276 mm, dual-piston floating caliper
ABS System
BMW Motorrad Integral ABS (part-integral, can be switched off)
Chassis and Suspension
Frame
Two section frame, front - and bolted on rear frame, load bearing engine
Front Suspension
Upside-down telescopic fork, Ø 45 mm
Travel : 140 mm
Rear Suspension
Cast aluminum single-sided swing arm with BMW Paralever; WAD strut (travel-related damping), spring pre-load hydraulically adjustable (continuously variable) via handwheel, rebound damping adjustable
Travel : 140 mm
Tyres
Wheels / Rim
Cast aluminum wheels
Rim front : 3.50'' x 17''
Rim rear : 5.50'' x 17''
Front Tyre
120/70 ZR 17
Rear Tyre
180/55 ZR 17
Dimensions
Length
2202mm
Width
925mm
Height
1255mm
Wheelbase
1530 mm
Fuel Tank Capacity
18 litres
Reserve Tank Capacity
4 litres
Additional Details
Bore x stroke : 102.5 mm x 76 mm
Emission control : Closed-loop 3-way catalytic converter, emission standard EU-4
Fuel consumption : 50 mpg (WMTC)
Fuel type : Premium Unleaded
Alternator : Three-phase 508 W generator
Gearbox : Constant-mesh 6-speed gearbox with helical cut gears
Drive : Shaft drive
Castor : 110.9 mm
Steering head angle : 62.3°
Inner leg curve, unladen weight : Sport Seat: 73.8", Standard Seat: 72.4", Low Seat: 67.7"
Permitted total weight : 460 kg
Payload (with standard equipment) : 217 kg
