Mondraker Prime Plus Electric Bicycle Price, Specs and Features

Price, features and specs

Rate Mondraker Prime Plus:

4.5/5 (2 votes)

Compare
Write a Review

Mondraker Prime Plus Price

Not Available

Buy new Mondraker Prime Plus

Book a Test Drive through Bikes4Sale and we will try to get you the best offer for Mondraker Prime Plus.

For Exciting Offers, Book a Test Drive

Picture Gallery

Similar Bicycles

Jasion EB7 2.0

Gyroor C3

Retrospec Chatham Rev 2

Rad Power Bikes RadKick 7

Revi Rebel 2

Velotric Fold 1

Mondraker Dealers

BIOBIKE

Calle Lanzarote Nº 15 Local – 1 Spain

Contact Dealer

Bikeobiker

AVENIDA FRANCISCO AGUIRRE, 426, TALAVERA DE LA REINA Spain

Contact Dealer

More Dealers

View all Mondraker Showrooms

View All Showrooms

Technical Specifications

Vehicle Type	Bicycle
Fuel	Electric
Top Speed	25 kmph
Fork	RockShox Recon Silver RL 29, 120mm, Motion control, Solo Air, tapered tube, Boost 15x110mm axle, 42mm offset. Settings: compression down to lock, rebound, air preload
Chain	SRAM SX Eagle, 12v, Powerlock
Derailleur : Rear	SRAM SX Eagle, Type 3 needle bearing clutch, cage lock, 1x12v long cage, X-ACTUATION 1: 1
Hub : Front	Formula DC711, Boost 15x110mm, sealed bearings, IS 6 bolt
Hub : Rear	Formula EHL148, Boost 12x148mm, sealed bearings, IS 6 bolt
Spoke	SRAM X-SYNC 2 Eagle 34T, steel, Narrow / Wide, 104 BCD

Motor Details
Bosch Performance Line CX Cruise (25Km / h) GEN4

Display
Bosch Purion

Electricals
Battery	Bosch Powertube 625Wh

Brakes
Front Brake	SRAM Level T, two-piece caliper, one-piece IS 200mm 6-bolt Centerline rotor, organic pickups
Rear Brake	SRAM Level T, two-piece caliper, one-piece IS 180mm 6-bolt Centerline rotor, organic pickups
Brake Lever	SRAM Level T, Direct Link actuation, reach adjust with tools, lever spindle with bushings

Tyres
Front Tyre	Maxxis Rekon + 27.5x2.8, tubeless ready, dual compound, EXO shell, 60TPI, folding bead
Rear Tyre	Maxxis Rekon + 27.5x2.8, tubeless ready, dual compound, EXO shell, 60TPI, folding bead

Additional Details
Pinions : SRAM PG-1210, 11-50T, 12v Derailleur hanger : Mondraker M068 Controls - change buttons :SRAM Trigger SX Eagle, 12v, X-ACTUATION 1: 1 Shank : ONOFF Sulfur 0-R, 6061 T6 Alloy, 3D forged, diameter 31.6mm, length 400mm Power : ONOFF Sulfur FG 30mm 0º, forged 6061 alloy, for 31.8mm handlebars Connecting rods : Race Face Aeffect ebike, 165mm Radios : CN inox round Cuffs : ONOFF Diamond, 1 lock-on, 135mm Shock absorber : RockShox Deluxe Select R Debonair, 205x65mm. Settings: low rebound, air preload. Trunnion top anchor, 25x10mm bottom bushings. Sizes : XS: 380mm / S: 390mm / M: 430mm / L: 470mm / XL: 510mm

Additional Details

Pinions : SRAM PG-1210, 11-50T, 12v
Derailleur hanger : Mondraker M068
Controls - change buttons :SRAM Trigger SX Eagle, 12v, X-ACTUATION 1: 1
Shank : ONOFF Sulfur 0-R, 6061 T6 Alloy, 3D forged, diameter 31.6mm, length 400mm
Power : ONOFF Sulfur FG 30mm 0º, forged 6061 alloy, for 31.8mm handlebars
Connecting rods : Race Face Aeffect ebike, 165mm
Radios : CN inox round
Cuffs : ONOFF Diamond, 1 lock-on, 135mm
Shock absorber : RockShox Deluxe Select R Debonair, 205x65mm. Settings: low rebound, air preload. Trunnion top anchor, 25x10mm bottom bushings.
Sizes : XS: 380mm / S: 390mm / M: 430mm / L: 470mm / XL: 510mm
