Price, features and specs
2022 Stage Evo Factory is not in production now.
Rate Orange 2022 Stage Evo Factory:
Orange 2022 Stage Evo Factory Price
£
6100
[London, United Kingdom]
Orange has stopped the production of its bicycle 2022 Stage Evo Factory and hence the given price is not relevant.
The given price can change depending on the colour, accessories and other features.
| Country, City |
Showroom Price |
On Road Price |
| United Kingdom, London |
£ 6100 |
-- |
Features
- Single pivot suspension for the utmost performance, efficiency and reliability
- Radically revised progressive suspension frame curve
- Aggressive Evo geometry optimised for 130mm front/120mm rear travel
- Bottle cage mounts
- 29 inch wheels
- Boost 148 rear hub spacing
- Internal dropper post routing
Colours
Fizzy Orange
Norlando Grey
Matt Charcoal Grey
Smoke White
Gloss Cyan Blue
British Racing Green
Gloss Silver Shadow
Gloss Laser Blue
Technical Specifications
| Vehicle Type | Bicycle |
| Seating Capacity | 1 |
| Stem | Hope M35 x 35mm Black |
| Handlebar | Renthal FatBar M35 800mm |
| Fork | Fox Factory 36 Float 130mm 29 (black) |
| Seat | Strange Bolted |
| Seatpost | Fox Factory Transfer 175mm Drop |
| Grip | Strange Grappler Lock-On |
| Crankset | E13 Helix 32t 170mm |
| Chain | KMC 12spd |
| Shifters | Shimano XT 12spd |
| Saddle | SDG Strange Bel Air III |
| Headset | Cane Creek 49mm for Tapered Steerer |
| Hub : Rear | 12 x 148mm Boost |
| Cassette | Shimano XT 10-51T 12spd |
| Bottom Bracket | E13 |
| Brakes |
|---|
| Front Brake | Shimano XT Trail 203/180 |
| Chassis and Suspension |
|---|
| Frame | 6061-T6 Monocoque UK Formed Custom Aluminium Tubing |
| Rear Suspension | Fox Float X Factory 190x45 |
| Tyres |
|---|
| Wheels / Rim | Spoke |
| Rear Tyre | Maxxis Minion DHF 2.5 3C Exo / DHR II 2.4 Exo 29 |
| Dimensions |
|---|
| Wheelbase | 1198 mm |
| Additional Details |
Swingarm: Bolt Type Allen Key Head (Boost 148mm Hub)
Rear Mech: Shimano XT 12spd
Chain Device: E13 Vario Compact Guide
Wheelset: Stans Flow Mk4 + Hope Pro 4 (Black) 29
Fork Offset: 42 mm
Seatpost : 30.9 mm
Seatclamp : 34.9 mm
BB Shell: 73 mm ISCG05
Tapered Headset: Upper: ZS49/28.6
Lower: EC49/40 |
| Vehicle Warranty |
| 5 year frame warranty with Limited Lifetime Crash Replacement |
