Single disc brake, diameter 10.9" (276 mm), double-piston floating caliper
ABS System
BMW Motorrad Integral ABS Pro (part-integral, slant-layer-optimized)
Chassis and Suspension
Frame
Two-section frame, front- and bolted on rear frame, load-bearing engine
Front Suspension
BMW Motorrad Telelever; stanchion diameter 1.5" (37 mm), central spring strut
Suspension travel, front : 8.3" / 210 mm
Rear Suspension
Cast aluminium single-sided swing arm with BMW Motorrad Paralever; WAD strut (travel-related damping), spring pre-load hydraulically adjustable (continuously variable) at handwheel, rebound damping adjustable at handwheel
Suspension travel, rear : 8.7"/220 mm
Tyres
Wheels / Rim
Cross spoke wheels
Rim, front : 3.00 x 19"
Rim, rear :4.50 x 17"
Front Tyre
120/70 R 19
Rear Tyre
170/60 R 17
Dimensions
Length
2270mm
Width
980mm
Height
1460mm
Seat Height
890 mm
Wheelbase
1504 mm
Weight
268kg
Fuel Tank Capacity
29.9 litres
Reserve Tank Capacity
3.7 litres
Accessories
Optional equipments
- Dynamic ESA (Electronic Suspension Adjustment with automatic load levelling and automatic damping mode)
- Seat heating (rider and passenger)
- Handlebar riser
- Option 719 milled parts
- Ride Modes Pro, includes additional modes (Dynamic, Dynamic Pro, Enduro and Enduro Pro), riding mode pre selection (individualization of numbers of riding modes), automated hill start control pro (HSC Pro), dynamic brake assistent DBC and engine brake control MSR
- Style-variants Rallye and Triple Black
Additional Details
Mixture Control : Electronic intake pipe injection
Emission control : Closed-loop 3-way catalytic converter, emission standard EU-5
Fuel type : Unleaded super, octane number 95 (RON), adaptive fuel quality regulation (91 to 98 RON)
Alternator : Three-phase alternator with 510 Watt nominal power
Steering head angle : 65.1°
Caster : 3.8" (95.4 mm)
Inner leg curve : 76.8" / 78.3" (1,950 mm / 1,990 mm)
