Air/liquid-cooled 4-stroke flat twin engine, double overhead camshaft, one balance shaft and variable engine timing system BMW ShiftCam.
Engine Starting
Electric
Bore x Stroke
101.6mm x 76.2mm
Compression Ratio
12.5 : 1
Clutch
Oil lubricated clutch, hydraulically operated
Fuel System
Electronic fuel injection with ride-by-wire throttle system
Cooling System
Air/liquid-cooled
Maximum Power
136 PS @ 7750 rpm
Maximum Torque
142.3 NM @ 6250 rpm
Load Carrying Capacity
Permitted total weight: 460 kg
Payload (with standard equipment): 221 kg
Seating Capacity
2
Transmission
Constant-mesh 6-speed gearbox with helical cut gears
Gear Shift Pattern
1-N-2-3-4-5-6
Drivetrain
Shaft drive
Top Speed
201+kmph
Display
Digital
Electricals
Battery
12 V / 12 Ah
Head Lamp
LED
Tail Lamp
LED
Brakes
Front Brake
Dual floating disc brakes, 4-piston radial calipers, diameter 320 mm
Rear Brake
Single disc brake, diameter 276 mm, dual-piston floating caliper
ABS System
BMW Motorrad Integral ABS (part-integral, can be switched off)
Chassis and Suspension
Frame
Two section frame, front - and bolted on rear frame, load bearing engine
Front Suspension
Upside-down telescopic fork, Ø 1.77”
Rear Suspension
Cast aluminum single-sided swing arm with BMW Paralever; WAD strut (travel-related damping), spring pre-load hydraulically adjustable (continuously variable) via handwheel, rebound damping adjustable
Tyres
Wheels / Rim
Cast aluminum wheels
Front Tyre
3.50'' x 17''
120/70 ZR 17
Rear Tyre
5.50'' x 17''
180/55 ZR 17
Dimensions
Length
2166mm
Width
879mm
Height
1300mm
Seat Height
820 mm
Wheelbase
1514 mm
Kerb Weight
239 kg
Fuel Tank Capacity
18 litres
Reserve Tank Capacity
4 litres
Additional Details
Emission control: Closed-loop 3-way catalytic converter
Fuel type: Premium Unleaded
Alternator: Three-phase 508 W generator
Caster: 4.9" (125.6 mm)
Steering head angle: 62.3°
Inner leg curve, unladen weight: Sport Seat: 73.8", Standard Seat: 72.4", Extra Low Seat: 67.7"
