Water-cooled DOHC88° V-twin four-stroke with four valves per cylinder and composite chain / gear cam drive
Engine Starting
Electric
Bore x Stroke
94mm x 71.8mm
Compression Ratio
11 : 1
Clutch
Multiplate oil-bath clutch with hydraulic operation
Fuel System
Electronic fuel injection with Synerject ECU and 2 x 50 mm Synerject throttle bodies, each with a single injector
Cooling System
Water-cooled
Maximum Power
102bhp (75kW) @ 9600rpm Euro 4 Homologation
Maximum Torque
87Nm (64lb-ft) @ 7300rpm
Transmission
6-Speed
Gear Shift Pattern
1-N-2-3-4-5-6
Electricals
Head Lamp
LED
Tail Lamp
LED
Brakes
Front Brake
4 x 230mm Beringer Stainless Steel discs with 2 x four-piston Beringer radial calipers
Rear Brake
1 x 230mm Beringer Stainless Steel disc with 1 x two-piston Beringer radial caliper
Chassis and Suspension
Frame
Machined Titanium frame with Titanium subframe
Front Suspension
Fior-type fork CNC machined from solid aluminum with twin articulated triangular titanium links and Preload and rebound adjustable mono-shock with 120mm travel
Rear Suspension
Cast aluminum swingarm pivoting in engine crankcases, with monoshock adjustable for preload and rebound damping and progressive rate link with 130mm travel
Tyres
Wheels / Rim
Machined aluminum wheels (18 spokes)
Front Tyre
120/70 - 18’’ on 3.50 inches
Rear Tyre
160/60 - 18’’ on 4.25 inches
Dimensions
Length
2180mm
Width
760mm
Seat Height
820 mm
Wheelbase
1540 mm
Weight
186kg
Additional Details
Head Angle / Trail: 23.365° with 93.65mm trail via 38mm fork offset
