Price, review, features and specs
Cleveland Cyclewerks FXr Price
Not Available
Buy new Cleveland Cyclewerks FXr
Book a Test Drive through Bikes4Sale and we will try to get you the best offer for Cleveland Cyclewerks FXr.
For Exciting Offers, Book a Test Drive
Picture Gallery
Green
Similar Motorcycles
Colours
Green
Black
Blue
Technical Specifications
| Vehicle Type | Motorcycle |
| Fuel | Petrol |
| Engine Displacement | 125.00 cc |
| Engine Details | 4-Stroke,OHC horizontal single cylinder four stroke |
| Engine Starting | Electric and Kick |
| Bore x Stroke | 54mm x 54mm |
| Compression Ratio | 9.3:1 |
| Clutch | Manual wet multi-plate |
| Ignition | CDI |
| Cooling System | Air cooled |
| Maximum Power | 8.3 PS 8500 RPM |
| Maximum Torque | 8.5 NM @ 7500 RPM |
| Transmission | Constant mesh, 4-speed |
| Gear Shift Pattern | 1-N-2-3-4 |
| Electricals | |
|---|---|
| Battery | MBT4XU AGM maintenance free,12 V 4.7 A-h |
| Chassis and Suspension | |
|---|---|
| Frame | CCW Cradle perimeter frame CCW Cradle perimeter frame Integral fuel tank |
| Front Suspension | Inverted 33mm stanchions Ф48 x Ф51 780mm Length Cartridge damping Shim stack valving for rebound and compression Lower guards |
| Rear Suspension | Single shock 290mm Lenth Adjustable compression and rebound 335 Pound spring Threaded preload adjustment 0.8MPA(125PSI) Air pressure |
| Tyres | |
|---|---|
| Wheels / Rim | Front wheel : 1.6 x 21 Aluminum rim Rim lock fitted Rear wheel : 1.6 x 21 Aluminum rim Rim lock fitted |
| Front Tyre | Yuanxing 80/100-21 DOT/E4 tube type DOT/E4 tube type YX-P153-02 Max load 429lbs (195kg) @32 psi (225kPa) |
| Rear Tyre | Yuanxing 80/100-21 51M Yuanxing 80/100-21 51M Tube type YX-P153-02 YX-P153-02 Max load 429lbs (195kg) @32 psi (225kPa) |
| Dimensions | |
|---|---|
| Length | 2075 mm |
| Width | 850 mm |
| Height | 1180 mm |
| Seat Height | 860 mm |
| Wheelbase | 1310 mm |
| Kerb Weight | 87 kg |
| Additional Details |
|---|
| Shift Lever : Steel Kick Starter : Steel Carb : 22mm Spark Plug : NGK Air Filter : Foam Style / Sponge Fork : Non Adjustable T7 Series Handlebar : Steel Handle Bar Handlebar Riser : Alloy, 4 Piece Shock : Non Adjustable T7 Series Swing Arm : Steel |
