Technical Specifications
Vehicle TypeMotorcycle
FuelPetrol
Engine Displacement125.00 cc
Engine DetailsOHC horizontal single cylinder four stroke
Engine StartingElectric and kick
Bore x Stroke54mm x 54mm
Compression Ratio9.3:1
ClutchManual wet multi-plate
IgnitionCDI
Cooling SystemAir cooled
Maximum Power8.3 PS 8500 RPM
Maximum Torque8.5 NM @ 7500 RPM
TransmissionConstant mesh, 4-speed
Gear Shift Pattern1-N-2-3-4
Electricals
BatteryMBT4XU AGM maintenance free,12V 4.7 A-h
Brakes
Front BrakeSingle 210mm rotor 2 piston slide caliper DOT brake hose
Rear Brake200mm single rotor 2 piston slide caliper DOT braided and bonded stainless steel brake hose
Chassis and Suspension
FrameCCW Cradle perimeter frame CCW Cradle perimeter frame Integral fuel tank
Front SuspensionInverted 33mm stanchions Ф48 x Ф51 780mm Length Cartridge damping Shim stack valving for rebound and compression Lower guards
Rear SuspensionSingle shock 290mm Lenth Adjustable compression and rebound 335 Pound spring Threaded preload adjustment 0.8MPA(125PSI) Air pressure
Tyres
Wheels / RimFront wheel : 1.6 x 21 Aluminum rim Rim lock fitted
Rear wheel : 1.6 x 21 Aluminum rim Rim lock fitted
Front TyreYuanxing 80/100-21 DOT/E4 tube type DOT/E4 tube type YX-P153-02 Max load 429lbs (195kg) @32 psi (225kPa)
Rear TyreYuanxing 80/100-21 51M Yuanxing 80/100-21 51M Tube type YX-P153-02 YX-P153-02 Max load 429lbs (195kg) @32 psi (225kPa)
Dimensions
Length x Width x Height2010 x 850 x 1180 mm
Seat Height860 mm
Wheelbase1310 mm
Kerb Weight85 kg
Ground Clearance360 mm
Fuel Tank Capacity3.2 litres
Additional Details
Primary Reduction : 3.722
First gear ratio : 3.273
Second gear ratio : 1.938
Third gear ratio : 1.35
Fourth gear ratio : 1.043
Final drive : KMC 428H roller chain
Front sprocket : 15T
Rear sprocket : 51T
Fuel : Unleaded gasoline
Minimum fuel octane : 87 (R+M/2)
Carburetor model : KF PZ26
Air filter : Stainless steel mesh
Exhaust emission System : 1 x three way catalyst in exhaust
Engine oil capacity : 0.9 l
Rake : 24 degree
Trail : 115 mm
Swingarm : High strength steel
Fork clamps top : Cast aluminum
Fork clamps bottom : Cast aluminum
Handle bar : Tapered aluminum 1-1/8"
Handle bar clamp : Cast aluminum
Stem bearings : Ball/race
