CUBE Aim EX 2022 Bicycle: Price, Review, Specs and Features

Price, review, features and specs

Rate CUBE Aim EX 2022:

4.2/5 (5 votes)

Add To Compare
Write a Review

CUBE Aim EX 2022 Price

Not Available

Buy new CUBE Aim EX 2022

Book a Test Drive through Bikes4Sale and we will try to get you the best offer for CUBE Aim EX 2022.

Picture Gallery

Similar Bicycles

A2 SP1.4 Compare

A2 SP1.3 Compare

A2 SP1.2HRD Compare

A2 SP1.2 Compare

A2 SP1.1 Compare

A2 RP3e Compare

Colours

Grey and Red
Desert and Black

134 Flushing Ave, United States

Via Bergamo 3a, Italy

More Dealers

View all CUBE Showrooms

Technical Specifications

Vehicle Type	Bicycle
Stem	CUBE Performance Stem Pro, 31.8mm
Handlebar	CUBE Rise Trail Bar, 680mm
Fork	SR Suntour XCM Disc, 100mm, Remote Lockout
Seat	SeatClamp: CUBE Varioclose, 31.8mm
Seatpost	CUBE Performance Post, 27.2mm
Grip	ACID React
Crankset	ACID MTB Alloy 32T
Pedals	CUBE PP MTB
Chain	KMC X10
Shifters	Shimano Deore SL-M4100, Rapidfire-Plus
Saddle	Natural Fit Venec Lite
Headset	CUBE FPH868, Top 1 1/8", Bottom 1 1/2", Semi-Integrated
Derailleur : Rear	Shimano Deore RD-M5120-SGS, 10-Speed
Hub : Front	CUBE Alloy Light, QR, 6-Bolt
Hub : Rear	CUBE Alloy Light, QR, 6-Bolt
Cassette	Sunrace CSM52, 11-46T
Bottom Bracket	Thun Paso-ML, 73mm BSA

Brakes
Front Brake	Clarks Clout 1, Hydr. Disc Brake (160/160)
Rear Brake	Clarks Clout 1, Hydr. Disc Brake (160/160)

Chassis and Suspension
Frame	Aluminium Lite, AMF, Double Butted, Internal Cable Routing, Tapered Head Tube, Flat Mount Brake, SIC Mount, FM Kickstand Mount

Dimensions
Weight	13.9 kg

Additional Details
Size Split: 27.5: XS (14"), S (16") // 29: M (18"), L (20"), XL (22"), XXL (24")
