Felt AR Advanced Ultegra

Price, review, features and specs

Rate Felt AR Advanced Ultegra:
3.7/5 (3 votes)
Add To Compare
Write a Review
Felt AR Advanced Ultegra Price $ 5499 [Albuquerque, United States]

The given price can change depending on the colour, accessories and other features.

Country, City Showroom Price On Road Price
United States, Albuquerque $ 5499 --
United States, Anchorage $ 5499 --
United States, Atlanta $ 5499 --
United States, Austin $ 5499 --
United States, Baltimore $ 5499 --
United States, Billings $ 5499 --
United States, Birmingham $ 5499 --
View price in other cities
Buy new Felt AR Advanced Ultegra

Book a Test Drive through Bikes4Sale and we will try to get you the best offer for Felt AR Advanced Ultegra.

For Exciting Offers, Book a Test Drive
By submitting, you agree to our Terms & Conditions.
- Aero seatpost slot covers
- Di2 battery charger
- Chain plate protector
- Tubeless valve stems
- Carbon assembly paste
- Headset top cover for use with non-integrated stem
Similar Bicycles
Technical Specifications
Vehicle TypeBicycle
StemAR integrated carbon with internal cable and hose routing -6¡ rise, ¯31.8 mm, 48 - 51 cm: 90 mm, 54 - 56 cm: 100 mm, 58 cm: 110 mm, 61 cm: 120 mm
HandlebarDevox Carbon Aero, 80 mm reach, 125 mm drop, ¯31.8 mm, 48 - 54 cm: 400 mm, 56 - 61 cm: 420 mm
ForkFelt Aero Road UHC Advanced + TeXtreme carbon fiber monocoque construction, AeroTaper 1.125" - 1.25" carbon fiber steerer tube, integrated crown race, crown and blades. Flat mount disc standard, 12 x 100 mm thru axle
SeatpostFelt VariMount Aero Road UHC Advanced + TeXtreme carbon fiber with high-frequency vibration reducing insert, integrated battery holder, 350 mm length*, 0/20 mm offset *Seatpost can be cut to length
CranksetShimano Ultegra R8000, 52/36T, 48 cm: 165 mm, 51 cm: 170 mm, 54 - 56 cm: 172.5 mm, 58 - 61 cm: 175 mm
ChainShimano 11-speed
ShiftersShimano Ultegra R8020 11-speed
SaddlePrologo Dimension T4.0
HeadsetFSA integrated sealed cartridge bearings MR121 {870E-RS} Upper bearing and MR168 {970E-RS} lower bearing with integrated aero headset spacers and integrated top cover for use with non-integrated stem
Hub : FrontReynolds Series 1, straight-pull design, 4 pawl, 24T ratchet, 11-speed, 12 x 142 mm thru axle, Center Lock
Hub : RearReynolds Series 1, straight-pull design, 12 x 100 mm thru axle, Center Lock
SpokeSapim Sprint bladed
CassetteShimano 11-speed, 11-30T
Front BrakeShimano BR8070 hydraulic disc, 160 mm rotor
Rear BrakeShimano BR8070 hydraulic disc, 140 mm rotor
Brake LeverShimano Ultegra R8020, hydraulic
Chassis and Suspension
FrameMMC with InsideOut construction, carbon fiber BB386 bottom bracket shell, 12 x 142 mm Syntace style thru axle, flat mount disc brake standard, aluminum replaceable rear derailleur hanger, internal electronic-specific cable routing, and high-frequency vibration reducing seat post insert.
Wheels / RimReynolds AR58 DB Custom carbon, tubeless ready, 21 mm inner width, 58 mm depth
Front TyreContinental Grand Prix 5000 folding, 700 x 25c
Rear TyreContinental Grand Prix 5000 folding, 700 x 25c
Length x Width x Height-- x -- x -- mm
Additional Details
Bar Tape : Felt VelvetGel tape with 3M reflective base with Felt Bubble-Tech F-Wing bar end plugs
Bottom Bracket : Token BB386 with 24mm bearings
Seatpost Clamp : Felt Internaloc integrated with titanium bolts
Thru Axle : Front: 12 x 100 x 118, thread: M12 x 1.5P x 13L, Maxle; Rear: 12 x 142 x 161 (161L + 9 head = 170 total), thread: M12 x 1.0P x 18L, Syntace
