Honda Pioneer SXS 520 M2M ATV

Price, features and specs

The Honda Pioneer SXS 520 M2M is a robust ATV designed for practicality. Its 518cc liquid-cooled single-cylinder engine delivers reliable power, while electronic fuel injection ensures efficient performance. With a towing capacity of 454 kg and a rear rack capacity of 204 kg, it's a workhorse in the field.

The five-speed automatic transmission with paddle shifting and 2WD/4WD modes provides versatility. Front and rear independent double-wishbone suspension offers a comfortable ride, boasting 5.8 and 5.9 inches of travel, respectively. The 24-inch tires provide stability, and the generous 215mm ground clearance allows for off-road adventures. The Honda Pioneer SXS 520 M2M is a capable and practical choice for those seeking a dependable ATV.

Rate Honda Pioneer SXS 520 M2M:
3.7/5 (3 votes)
Honda Pioneer SXS 520 M2M Price £ 11515 [London, United Kingdom]

The given price can change depending on the colour, accessories and other features.

Country, City Showroom Price On Road Price
United Kingdom, London £ 11515 --
Technical Specifications
Vehicle TypeATV
FuelPetrol
Engine Displacement518.00 cc
Engine DetailsLiquid cooled single cylinder four-stroke
Engine StartingElectric
Bore x Stroke96.0mm x 71.5mm
Fuel SystemElectronic fuel injection (PGM-FI), 36mm throttle body
IgnitionFull-transistorized type with electronic advance
Load Carrying CapacityTowing Capacity (kg): 454 kg
Rear Rack Capacity (kg): 204 kg (Bed Capacity)
TransmissionFive-speed automatic transmission with AT/MT modes with paddle shifting and reverse. Two drive modes include 2WD and 4WD
DrivetrainDirect front and rear driveshafts
Brakes
Front BrakeDual 200mm hydraulic disc
Rear Brake170mm hydraulic disc
Chassis and Suspension
Front SuspensionIndependent double-wishbone; 5.8 inches of travel
Rear SuspensionIndependent double-wishbone with preload adjustablility; 5.9 inches of travel
Tyres
Front Tyre24 x 8-12
Rear Tyre24 x 10-12
Dimensions
Length2670 mm
Width1270 mm
Height1810 mm
Wheelbase1850 mm
Ground Clearance215 mm
Fuel Tank Capacity15 litres
