The Honda Pioneer SXS 520 M2M is a robust ATV designed for practicality. Its 518cc liquid-cooled single-cylinder engine delivers reliable power, while electronic fuel injection ensures efficient performance. With a towing capacity of 454 kg and a rear rack capacity of 204 kg, it's a workhorse in the field.
The five-speed automatic transmission with paddle shifting and 2WD/4WD modes provides versatility. Front and rear independent double-wishbone suspension offers a comfortable ride, boasting 5.8 and 5.9 inches of travel, respectively. The 24-inch tires provide stability, and the generous 215mm ground clearance allows for off-road adventures. The Honda Pioneer SXS 520 M2M is a capable and practical choice for those seeking a dependable ATV.
The given price can change depending on the colour, accessories and other features.
| Country, City | Showroom Price | On Road Price |
|---|---|---|
| United Kingdom, London | £ 11515 | -- |
Book a Test Drive through Bikes4Sale and we will try to get you the best offer for Honda Pioneer SXS 520 M2M.
| Vehicle Type | ATV |
| Fuel | Petrol |
| Engine Displacement | 518.00 cc |
| Engine Details | Liquid cooled single cylinder four-stroke |
| Engine Starting | Electric |
| Bore x Stroke | 96.0mm x 71.5mm |
| Fuel System | Electronic fuel injection (PGM-FI), 36mm throttle body |
| Ignition | Full-transistorized type with electronic advance |
| Load Carrying Capacity | Towing Capacity (kg): 454 kg Rear Rack Capacity (kg): 204 kg (Bed Capacity) |
| Transmission | Five-speed automatic transmission with AT/MT modes with paddle shifting and reverse. Two drive modes include 2WD and 4WD |
| Drivetrain | Direct front and rear driveshafts |
| Brakes | |
|---|---|
| Front Brake | Dual 200mm hydraulic disc |
| Rear Brake | 170mm hydraulic disc |
| Chassis and Suspension | |
|---|---|
| Front Suspension | Independent double-wishbone; 5.8 inches of travel |
| Rear Suspension | Independent double-wishbone with preload adjustablility; 5.9 inches of travel |
| Tyres | |
|---|---|
| Front Tyre | 24 x 8-12 |
| Rear Tyre | 24 x 10-12 |
| Dimensions | |
|---|---|
| Length | 2670 mm |
| Width | 1270 mm |
| Height | 1810 mm |
| Wheelbase | 1850 mm |
| Ground Clearance | 215 mm |
| Fuel Tank Capacity | 15 litres |
