Final Drive : Selectable 2WD/4WD with locking front differential, shaft
Display
Multi-function digital meter with speedometer, fuel gauge, clock, hour meter, odometer, dual trip meter and parking-brake indicator, R/N/P/4WD, water temp and low-oil-pressure indicators
Electricals
Head Lamp
(2) incandescent headlights
Tail Lamp
(2) LED taillights
Brakes
Front Brake
Dual hydraulic discs with two-piston calipers
Rear Brake
Sealed, oil-bathed, multi-disc
Chassis and Suspension
Frame
Steel Tube Double-X Reinforcement
Front Suspension
Double Wishbone; Fox Podium coil-over shocks with piggyback reservoir, adjustable preload and 24-way compression damping/8.0 in.
Rear Suspension
Double Wishbone; Fox Podium coil-over shocks with piggyback reservoir, adjustable preload and 24-way compression damping/8.0 in.
Tyres
Wheels / Rim
Steel
Front Tyre
Maxxis 26 x 9-12
Rear Tyre
Maxxis 26 x 11-12
Dimensions
Length
3185mm
Width
1524mm
Height
1976mm
Wheelbase
2174 mm
Kerb Weight
1605 kg
Ground Clearance
284 mm
Fuel Tank Capacity
30 litres
Additional Details
- Engine Braking : Yes
- Steering : Electric Power Steering (EPS) / rack-and-pinion
- Turning Radius : 16.7 ft
- Cargo Bed Dimensions (LxWxH) : 17.9 x 47.6 x 8.7 in
- Cargo Bed Capacity : 249 lb
- Towing Capacity : 1300 lb
Vehicle Warranty
Kawasaki Strong 3-Year Limited Warranty
Kawasaki Protection Plus (optional) : 12, 24, or 36 months
