Marin 2022 Alpine Trail E1
- Home ››
- Bikes ››
- Marin ››
- 2022 Alpine Trail E1
Price, review, features and specs
The Marin 2022 Alpine Trail E1 mountain bike is an advanced full-suspension electric bike designed for serious mountain biking enthusiasts. It is built around a lightweight carbon fiber frame with a powerful Shimano EP8 motor and a 630Wh battery, giving riders the ability to tackle even the most challenging terrain with ease.
This bike features 160mm of front and rear travel, as well as a progressive suspension system that provides excellent traction and control on technical descents. It also has a modern geometry that strikes a balance between stability and agility, making it suitable for a variety of riding styles.
Other notable features of the Marin 2022 Alpine Trail E1 mountain bike include a wide range of gears, hydraulic disc brakes, and tubeless-ready wheels and tires. With its high-performance components and advanced technology, this bike is a great choice for riders who want to push their limits on the trail.
The given price can change depending on the colour, accessories and other features.
| Country, City | Showroom Price | On Road Price |
|---|---|---|
| United States, Phoenix | $ 4899 | -- |
Book a Test Drive through Bikes4Sale and we will try to get you the best offer for Marin 2022 Alpine Trail E1.
For Exciting Offers, Book a Test Drive
| Vehicle Type | Bicycle |
| Fuel | Electric |
| Stem | Marin 3D Forged Alloy, 35 mm |
| Handlebar | Marin Mini-Riser, 6061 Double Butted Aluminum, 780 mm Width, 28 mm Rise, 5º Up, 9º Back |
| Fork | Rock Shock 35 Gold RL 29", Motion Control Damper, 160 mm Travel, Maxle Stealth Axle, 44 mm Offset |
| Seatpost | TranzX, YSP23JL, 1x Remote, Size S 125 mm Travel, Size M and L 150 mm Travel, Size XL 170 mm Travel, 30.9 mm |
| Grip | Marin Single Clamp Locking |
| Crankset | Marin Forged Alloy 165 mm Length, Narrow Wide 38T Chainring, e13 Plus Chain guide, Aluminum Plate |
| Pedals | Marin MTB Plastic |
| Chain | KMC X-10E, E-Bike Specific, Silver |
| Saddle | Marin E-MTB Saddle |
| Headset | FSA No 57, Sealed Cartridge Bearings, 1 1/8" x 1 1/2” |
| Derailleur : Rear | Shimano Deore 5100 Direct Attachment, 10-Speed |
| Hub : Front | Shimano MT-410B, 110 x 15 mm, Centerlock Disc, 32H |
| Hub : Rear | Shimano HB-MT400B, 148 x 12 mm, Centerlock, Standard Freehub Body |
| Spoke | 14g Black Stainless Steel |
| Cassette | Shimano Deore M4100-10 10-speed 11-46T |
| Motor Details |
|---|
| Shimano STEPS E7000, 250W, 60Nm |
| Display |
|---|
| SC-E7000 Display |
| Electricals | |
|---|---|
| Battery | BT-8035, Internal 504Wh |
| Brakes | |
|---|---|
| Front Brake | Shimano MT420, 4-Piston Hydraulic Disc Brake, 203 mm Rotor |
| Rear Brake | Shimano MT420, 4-Piston Hydraulic Disc Brake, 203 mm Rotor w/ Speed Sensor |
| Brake Lever | Shimano MT4100 Hydraulic Lever, I-Spec EV Compatible |
| Chassis and Suspension | |
|---|---|
| Frame | All New Series 4 Alloy Frame, 150 mm Multitrac suspension, Integrated Battery/On-switch/Charging Port, 148mm Rear Thru-Axle, Built-in Rear Speed Sensor |
| Tyres | |
|---|---|
| Wheels / Rim | Front : Marin Aluminum Double Wall, 29" Diameter, 32 mm Inner Rim Width, Pinned Joint, Disc Specific, Tubeless Compatible Rear : Marin Aluminum Double Wall, 27.5" Diameter, 38 mm Inner Rim Width, Pinned Joint, Disc Specific, Tubeless Compatible |
| Front Tyre | Vee Tire Co Attack HPL, 29 x 2.5", Top 40 Tubeless Compatible |
| Rear Tyre | Vee Tire Co Crown Gem, 27.5 x 2.8”, TACKEE Compound, Tubeless Compatible |
| Additional Details |
|---|
| Size Range : S, M, L, XL Shock : Rock Shock Super Deluxe Coil R, Rebound Adjustment, 205 x 65 mm, 25 mm x M8 Lower Hardware, S/M Spring Rate = 300lb, L/XL Spring Rate = 400lb Shift Lever : Shimano Deore M4100-R, I-Spec EV, 10-Speed Switch : SW-E7000 Left Hand Switch for Assist Mode Change Shimano Battery Charger EC-E6002, Bolt-on Thru-Axle |
