Price, review, features and specs
Rate Marin Mount Vision 9:
The given price can change depending on the colour, accessories and other features.
Country, City |
Showroom Price |
On Road Price |
United States, Sparks |
$ 6399 |
-- |
Buy new Marin Mount Vision 9
Book a Test Drive through Bikes4Sale and we will try to get you the best offer for Marin Mount Vision 9.
For Exciting Offers, Book a Test Drive
The Hub-Co100 Country Center Dr
Suite F
Colorado United States
Contact Dealer Biking Roots3315 Spring Cypress Rd
Suite 5E
Texas United States
Contact Dealer
Features
- Naild R3ACT – 2 Play Suspension
- Ground Tracing
- Size-Specific Kinematics
- Carbon Fiber Frame
Technical Specifications
Vehicle Type | Bicycle |
Stem | Deity Copperhead Stem, 35 mm |
Handlebar | Deity Skyline, 787 mm Width, 25 mm Rise, Custom Color |
Fork | Fox Performance Elite 36 27.5", 150 mm Travel, GRIP 2 Damper, High and Low Speed Compression Adjustment, Rebound Adjustment, 110 x 15 mm Boost Spacing, 44 mm Offset |
Seatpost | KS LEV Integra Dropper Post, Southpaw Lever, Size S 125 mm Travel, All Other Sizes: 150 mm Travel, 30.9 mm |
Grip | Marin Locking |
Crankset | SRAM Descendant Carbon, Direct Mount 12-Speed 32T, Boost Spacing, DUB, 170 mm |
Chain | SRAM GX Eagle |
Shifters | Shift Lever : SRAM GX Eagle, 1x12-Speed |
Saddle | WTB Volt Race |
Headset | FSA Orbit, No. 42/47/ACB/S-4, Sealed Cartridge Bearings, 1 1/8"x 1 1/2” |
Derailleur : Rear | SRAM X01 Eagle,12-Speed |
Hub : Front | Forged Alloy, 148 x 12 mm, Quad Sealed Bearings, 6-Bolt Disc, 32H, XD Driver |
Hub : Rear | Forged Alloy, 110 x 15 mm, 6-Bolt Disc, 32H |
Spoke | 14 g Black Stainless Steel |
Cassette | SRAM XG-1295 12-Speed, 10-50T |
Brakes |
Front Brake | Shimano XT 4 Piston, M8020, 203 mm Rotor |
Rear Brake | Shimano XT 4 Piston, M8020, 180 mm Rotor |
Brake Lever | Shimano XT |
Chassis and Suspension |
Frame | Full Unidirectional Carbon Fiber Frame, Naild R3ACT – 2 Play Suspension Technology, 27.5" Wheels, 150 mm Travel, 148 mm Boost Rear Spacing, Bolt On Thru-Axle |
Tyres |
Wheels / Rim | Stan's NoTubes Sentry MK3, 32 mm Inner, Welded Joint, BST Technology, Tubeless Compatible |
Front Tyre | WTB Trail Boss 27.5 x 2.6", Tri-Tech Triple Compound, Fast Rolling, Light Casing with Slash Guard, TCS Aramid Bead, Tubeless Compatible |
Rear Tyre | WTB Trail Boss 27.5 x 2.6", Tri-Tech Triple Compound, Fast Rolling, Light Casing with Slash Guard, TCS Aramid Bead, Tubeless Compatible |
Dimensions |
Length x Width x Height | -- x -- x -- mm |
Additional Details |
Shock : Fox Float X2 Performance, 205 x 50 mm, Low Speed Compression Adjustment, Low Speed Rebound Adjustment, Custom Tune, Trunnion Mount
Bottom Bracket : SRAM GXP BB92 |
