Three cylinder, 4 stroke, 12 valve , “D.O.H.C” with mechanical chain tensioner and DLC tappet
Engine Starting
Electric
Bore x Stroke
79mm x 54.3mm
Compression Ratio
12.3:1
Clutch
Multi-disc wet clutch with hydraulic actuation and back torque limiting device
Cooling System
Cooling with separated liquid and oil radiators
Maximum Power
112 HP @ 11000 RPM
Maximum Torque
85 NM @ 8500 RPM
Transmission
Cassette style; six speed, constant mesh
Gear Shift Pattern
1-N-2-3-4-5-6
Drivetrain
Primary drive : 22/41
Final drive ratio : 16/41
Top Speed
237.0kmph
Gear
First gear: Speed
13/37
Second gear: Speed
16/35
Third gear: Speed
18/32
Fourth gear: Speed
20/30
Fifth gear: Speed
22/29
Sixth gear: Speed
21/25
Motor Details
Voltage :12 V
Display
Digital
Electricals
Battery
12 V - 8.5 Ah
Head Lamp
LED
Tail Lamp
LED
Brakes
Front Brake
Double floating disc with Ø 320 mm (Ø 12.6 in.) diameter, with steel braking disc and flange
Front brake caliper : Brembo radial-type, with 4 pistons Ø 32 mm (Ø 1.26 in.)
Rear Brake
Single steel disc with Ø 220 mm (Ø 8.66 in.) dia.
Rear brake caliper : Brembo with 2 pistons — Ø 34 mm (Ø 1.34 in.)
ABS System
Continental MK100 with RLM (Rear Wheel Lift-up Mitigation) and with cornering function
Chassis and Suspension
Frame
ALS Steel tubular trellis
Rear swing arm pivot plates material : Aluminium alloy
Front Suspension
43 mm Marzocchi “UPSIDE DOWN” telescopic hydraulic fork with rebound-compression damping and spring preload external and separate adjustment
Rear Suspension
Progressive Sachs, single shock absorber with rebound and compression damping and spring preload adjustment
Tyres
Wheels / Rim
Front wheel : Aluminium alloy 3.50 ” x 17 ”
Rear wheel : Aluminium alloy 5.50 ” x 17 ”
Front Tyre
120/70 - ZR 17 M/C (58 W)
Rear Tyre
180/55 - ZR 17 M/C (73 W)
Dimensions
Length
2045mm
Width
875mm
Height
830mm
Wheelbase
1400 mm
Kerb Weight
175 kg
Ground Clearance
135 mm
Fuel Tank Capacity
16.5 litres
Additional Details
Engine management system :
Integrated ignition - injection system MVICS 2.1 (Motor & Vehicle Integrated Control System) with three injectors. Engine control unit Eldor Nemo 2.1, throttle body full ride by wire Mikuni, pencil-coil. Torque control with four maps, Traction Control with eight levels of intervention.
Electronic quick-shift : MV EAS 3.0 (Electronically Assisted Shift up & down)
Alternator : 350 W at 5000 r.p.m.
Single sided swing arm material : Aluminium alloy
Wheel travel : 130 mm
Fork travel : 125 mm
Fairing material : Thermoplastic
Trail : 1035 mm
Environmental Standard : Euro 5
Combined fuel consumption : 5.1 l/100 km
CO2 Emissions : 117 g/km
