Primary Belt & 420 Drive Chain
German Continental Brand, 8M CXA
Top Speed
48kmph
Motor Details
Type : PMSM
Voltage : 60 V
Mounting Position : Mid Weight / Motor External
Diameter : 7.0kg / 180 mm
Motor Axial Length : 130 mm
Peak Efficiency : 95.60%
Range
60 Miles @ 20 MPH average speed depending upon terrain
Charging Time
2.5-3.5 Hours
Display
LCD Digital Speedometer
Electricals
Battery
Type : 60V 32A Lithium Battery with 176 Panasonic Cells
Life Cycle : 500 Cycles (and then the capacity reduces step by step)
Charge Level : Integrated Battery LCD Display
Charger
10 A
Warranty for Battery
18 Months (or up to 20,000 miles on Battery which ever sooner)
Head Lamp
LED
Tail Lamp
LED
Chassis and Suspension
Frame
Swing Arm Material: No. 6061 T4 & T6 Aluminium Alloy
Front Suspension
DNM, RST or Fastace
Rear Suspension
Adj DNM, RST or Fastace Shock with TR Suspension Link System
Tyres
Wheels / Rim
Spoke Wheels
Front/Rear : 19 x 1.4 Alloy Hubs
Front Tyre
70/100-19 CST
Rear Tyre
70/100-19 CST
Dimensions
Length
1870mm
Width
780mm
Height
1040mm
Seat Height
880 mm
Wheelbase
1260 mm
Weight
51kg
Ground Clearance
270 mm
Additional Details
Controller Type: X Version Sine Wave
Dimensions: 240 mm x 110 mm x 50 mm
Peak Efficiency: 98.50%
Rated Rotation Speed: 4300 RPM
Range of Efficiency (≥80): 1.4 Nm - 21.5 Nm
Power Modes: Eco and Sport Motor Power System
Horn : European Standard Horn
Max Load : 100kg (15.75 Stone)
Max Climb : 45° Rear Sprocket: 48T
Side Stand : Yes with kill switch
