Trek Fuel EX 5 Deore

Price, review, features and specs

Rate Trek Fuel EX 5 Deore:
3.5/5 (2 votes)
Add To Compare
Write a Review
Trek Fuel EX 5 Deore Price $ 2449 [Alabama, United States]

The given price can change depending on the colour, accessories and other features.

Country, City Showroom Price On Road Price
United States, Alabama $ 2449 --
United States, Alaska $ 2449 --
United States, Arizona $ 2449 --
United States, Atlanta $ 2449 --
United States, Austin $ 2449 --
United States, Baltimore $ 2449 --
United States, Boston $ 2449 --
View price in other cities
Buy new Trek Fuel EX 5 Deore

Book a Test Drive through Bikes4Sale and we will try to get you the best offer for Trek Fuel EX 5 Deore.

For Exciting Offers, Book a Test Drive
5889
Features
- Straight Shot with Knock Block
- Active Braking Pivot
- Control Freak Cable Management
- Suspension Calculator
- Mino Link Adjustable Geometry
- Alpha Platinum Aluminium
Colours

Lithium Grey/Marigold
Dark Aquatic/Trek Black

Technical Specifications
Vehicle TypeBicycle
Load Carrying CapacityCombined weight of bicycle, rider, and cargo of 300 pounds (136 kg)
StemBontrager Rhythm Comp, 31.8 mm, Knock Block, 0 degree, 50 mm length
HandlebarBontrager alloy, 31.8 mm, 15 mm rise, 750 mm width
ForkRockShox Recon Silver, DebonAir spring, Motion Control damper, lockout, tapered steerer, 42 mm offset, Boost110, Maxle Stealth, 140 mm travel
SeatpostSize : XS, S - TranzX JD-YSP18, 100 mm travel, internal routing, 31.6 mm, 361 mm length
Size : M, ML, L, XL - TranzX JD-YSP18, 130 mm travel, internal routing, 31.6 mm, 425 mm length
GripBontrager XR Trail Comp, nylon lock-on
CranksetShimano MT511, 30T steel ring, Boost (52 mm chainline), 170 mm length
ChainShimano Deore M6100, 12 speed
ShiftersShimano Deore M6100, 12 speed
SaddleBontrager Arvada, steel rails, 138 mm width
HeadsetKnock Block Integrated, 58-degree radius, cartridge bearing, 1-1/8'' top, 1.5'' bottom
Derailleur : RearShimano Deore M6100, long cage
Hub : FrontBontrager alloy, sealed bearing, alloy axle, 6-bolt, Shimano MicroSpline freehub, Boost148, 12 mm thru axle
Hub : RearBontrager alloy, 6-bolt, Boost110, 15 mm thru axle
Spoke14g stainless steel
CassetteShimano Deore M6100, 10-51, 12 speed
Chainrings34T
Bottom BracketShimano MT500, 92 mm, PressFit
Electricals
Battery
Brakes
Front BrakeShimano hydraulic disc, MT201 lever, MT200 caliper
Brake Rotor : Shimano RT56, 6-bolt, 180 mm
Rear BrakeShimano hydraulic disc, MT201 lever, MT200 caliper
Brake Rotor : Shimano RT56, 6-bolt, 180 mm
Chassis and Suspension
FrameAlpha Platinum Aluminum, tapered head tube, Knock Block, Control Freak internal routing, downtube guard, ISCG 05, magnesium rocker link, Mino Link, ABP, Boost148, 130 mm travel
Tyres
Wheels / RimAlex MD35, tubeless compatible, 32-hole, 35 mm width, presta valve
Front TyreBontrager XR4 Comp, wire bead, 30 tpi, 29 x 2.60''
Rear TyreBontrager XR4 Comp, wire bead, 30 tpi, 29 x 2.60''
Dimensions
Length x Width x Height-- x -- x -- mm
Weight34.61 kg
Additional Details
Shock : X-Fusion Pro 2, 2-position damper, 210 x 55 mm
Max compatible fork travel : 150 mm (561 mm axle-to-crown)
