Trek Fuel EX 5

Price, review, features and specs

Rate Trek Fuel EX 5:
3.5/5 (2 votes)
Add To Compare
Write a Review
Trek Fuel EX 5 Price $ 2099 [Naples, United States]

The given price can change depending on the colour, accessories and other features.

Country, City Showroom Price On Road Price
United States, Naples $ 2099 --
Buy new Trek Fuel EX 5

Book a Test Drive through Bikes4Sale and we will try to get you the best offer for Trek Fuel EX 5.

For Exciting Offers, Book a Test Drive
670
Similar Bicycles
Colours

Slate / Trek Black
Trek Black / Purple Lotus

Technical Specifications
Vehicle TypeBicycle
StemBontrager Rhythm Comp, 31.8 mm, Knock Block, 0 degree
HandlebarBontrager alloy, 31.8 mm, 15 mm rise
ForkRockShox Recon RL, Solo Air spring, Motion Control damper, tapered steerer, 46 mm offset, Boost110, 15 mm Maxle Stealth, 140 mm travel
SeatpostTranzX JD-YSP18, 130 mm travel, internal routing, 31.6 mm
GripBontrager XR Trail Comp, lock-on
CranksetRace Face Ride, Boost
ChainKMC X10, 10 speed
ShiftersShimano Deore M6000, 10 speed
SaddleBontrager Arvada, steel rails
HeadsetKnock Block Integrated, cartridge bearing, 1-1/8 top, 1.5 bottom
Derailleur : RearShimano Deore M6000, mid cage, 42 T max cog
Hub : FrontFront: Formula DC-511, 6-bolt
Hub : FrontFront: Formula DC-511, 6-bolt
CassetteSunRace, 11-42, 10 speed
Chainrings30 T steel ring
Electricals
Battery
Brakes
Front BrakeShimano hydraulic disc, MT201 lever, MT200 caliper
Rear BrakeShimano hydraulic disc, MT201 lever, MT200 caliper
Chassis and Suspension
FrameAlpha Platinum Aluminum, tapered head tube, Knock Block, Control Freak internal routing, downtube guard, ISCG 05, magnesium rocker link, Mino Link, ABP, Boost148, 130 mm travel
Rear SuspensionRear Shock : RockShox Deluxe Select Plus, 210 x 55 mm
Tyres
Wheels / RimAlex MD35, Tubeless Ready, 32-hole, 35 mm width, presta valve
Front TyreBontrager XR4 Team Issue, Tubeless Ready, Inner Strength sidewalls, aramid bead, 120 tpi
Rear TyreBontrager XR4 Team Issue, Tubeless Ready, Inner Strength sidewalls, aramid bead, 120 tpi
Dimensions
Length x Width x Height-- x -- x -- mm
Additional Details
Axles
Front : 15 x 110 mm
Rear : 12 x 148 mm
Bottom Bracket : Shimano MT500, 92 mm, PressFit
