Trek Fuel EX 9.9 XTR

Price, review, features and specs

Rate Trek Fuel EX 9.9 XTR:
4.0/5 (3 votes)
Add To Compare
Write a Review
Trek Fuel EX 9.9 XTR Price $ 8499 [Alabama, United States]

The given price can change depending on the colour, accessories and other features.

Country, City Showroom Price On Road Price
United States, Alabama $ 8499 --
United States, Alaska $ 8499 --
United States, Arizona $ 8499 --
United States, Atlanta $ 8499 --
United States, Austin $ 8499 --
United States, Baltimore $ 8499 --
United States, Boston $ 8499 --
View price in other cities
Buy new Trek Fuel EX 9.9 XTR

Book a Test Drive through Bikes4Sale and we will try to get you the best offer for Trek Fuel EX 9.9 XTR.

For Exciting Offers, Book a Test Drive
7717
Features
- Internal Storage
- OCLV Mountain Carbon
- Active Braking Pivot
- Control Freak Cable Management
- Complete Tubeless System
- Carbon Care Wheel Loyalty Program
- Suspension Calculator
- Mino Link Adjustable Geometry
Colours

Lithium Grey/Factory Orange
Raw Carbon/Rage Red
Matte Carbon Smoke

Technical Specifications
Vehicle TypeBicycle
Load Carrying CapacityCombined weight of bicycle, rider, and cargo of 300 pounds (136 kg)
StemSize : XS, S - Bontrager Line Pro, 35 mm, Knock Block, Blendr compatible, 0 degree, 35 mm length
Size : M, ML, L, XL - Bontrager Line Pro, 35 mm, Knock Block, Blendr compatible, 0 degree, 45 mm length
HandlebarBontrager Line Pro, OCLV Carbon, 35 mm, 27.5 mm rise, 780 mm width
ForkFox Factory 36, Float EVOL air spring, GRIP2 damper, tapered steerer, 44 mm offset, Boost110, 15 mm Kabolt axle, 140 mm travel
SeatpostSize : XS, S - Bontrager Line Elite Dropper, 100 mm travel, internal routing, 31.6 mm, 340 mm length
Size : M, ML - Bontrager Line Elite Dropper, 150 mm travel, internal routing, 31.6 mm, 440 mm length
Size : L, XL - Bontrager Line Elite Dropper, 170 mm travel, internal routing, 31.6 mm, 480 mm length
GripBontrager XR Trail Elite, alloy lock-on
CranksetSize : XS, S - Shimano XTR M9120, 30T alloy ring, Boost (52 mm chainline), 170 mm length
Size : M, ML, L, XL - Shimano XTR M9120, 30T alloy ring, Boost (52 mm chainline), 175 mm length
ChainShimano XTR M9100, 12 speed
ShiftersShimano XTR M9100, 12 speed
SaddleBontrager Arvada Pro, carbon rails, 138 mm width
HeadsetKnock Block Integrated, 58-degree radius, cartridge bearing, 1-1/8'' top, 1.5'' bottom
Derailleur : RearShimano XTR M9100, Shadow Plus, long cage, 51T max cog
CassetteShimano XTR M9100, 10-51, 12 speed
Chainrings34T
Bottom BracketShimano MT500, 92 mm, PressFit
Electricals
Battery
Brakes
Front BrakeShimano XTR M9120 4-piston hydraulic disc
Brake Rotor : Shimano RT86, 180 mm, 6-bolt
Rear BrakeShimano XTR M9120 4-piston hydraulic disc
Brake Rotor : Shimano RT86, 203 mm, 6-bolt
Chassis and Suspension
FrameOCLV Mountain Carbon main frame & stays, internal storage, tapered head tube, Knock Block, Control Freak internal routing, Carbon Armor, ISCG 05, magnesium rocker link, Mino Link, ABP, Boost148, 130 mm travel
Tyres
Wheels / RimFront : NEW Bontrager Line Pro 30, OCLV Mountain Carbon, Tubeless Ready, 6-bolt, Boost110, 15 mm thru axle
Rear : Bontrager Line Pro 30, OCLV Mountain Carbon, Tubeless Ready, Rapid Drive 108, 6-bolt, Shimano MicroSpline freehub, Boost148, 12 mm thru axle
Front TyreBontrager XR4 Team Issue, Tubeless Ready, Inner Strength sidewall, aramid bead, 120 tpi, 29 x 2.40''
Rear TyreBontrager XR4 Team Issue, Tubeless Ready, Inner Strength sidewalls, aramid bead, 120 tpi, 29 x 2.60''
Dimensions
Length x Width x Height-- x -- x -- mm
Weight12.63 kg
Accessories
Bontrager BITS Internal Frame Storage Bag
Additional Details
Shock : Fox Factory Float EVOL, RE:aktiv with Thru Shaft 3-position damper, Kashima Coat, tuned by Trek Suspension Lab, 210 x 55 mm
Max compatible fork travel : 150 mm (561 mm axle-to-crown)
