The given price can change depending on the colour, accessories and other features.
| Country, City | Showroom Price | On Road Price |
|---|---|---|
| Thailand, Bangkok | ฿ 96400 | -- |
Book a Test Drive through Bikes4Sale and we will try to get you the best offer for Yamaha NMAX Connected 2022.
Green (Dark Petrol)
Red (Redline)
Gray (Prestige Gray)
| Vehicle Type | Scooter |
| Fuel | Petrol |
| Engine Displacement | 155.00 cc |
| Engine Details | 4-stroke, single-cylinder, SOHC, 4 valves, VVA technology, water-cooled |
| Engine Starting | Hand start with electric SMART MOTOR GENERATOR |
| Bore x Stroke | 58.0mm x 58.7mm |
| Compression Ratio | 11.6 : 1 |
| Engine Lubrication | wet |
| Clutch | Dry clutch, automatic centrifugal type |
| Ignition | TCI |
| Cooling System | water-cooled |
| Seating Capacity | 2 |
| Transmission | Automatic V-belt (V – Belt) |
| Display |
|---|
| Digital |
| Electricals | |
|---|---|
| Battery | 12 V, 5.0 Ah / YTZ6V (MF) |
| Head Lamp | LED |
| Tail Lamp | LED |
| Brakes | |
|---|---|
| Front Brake | single disc brake |
| Rear Brake | single disc brake |
| Chassis and Suspension | |
|---|---|
| Frame | backbone |
| Front Suspension | Telescopic |
| Rear Suspension | swing unit |
| Tyres | |
|---|---|
| Wheels / Rim | Alloy |
| Front Tyre | 110/70-13M/C 48P |
| Rear Tyre | 130/70-13M/C 63P |
| Dimensions | |
|---|---|
| Length | 1935 mm |
| Width | 740 mm |
| Height | 1160 mm |
| Seat Height | 765 mm |
| Kerb Weight | 131 kg |
| Ground Clearance | 125 mm |
| Fuel Tank Capacity | 7.1 litres |
| Additional Details |
|---|
| Spark plug type: NGK/CPR8EA-9 oil supply system: Injector type Auto ratio (front/rear): 2.239-0.706 : 1 final gear ratio: 10.208 (56/16 x 35/12) air filter: oil-coated paper filter |
