Up to 28 MPH on Pedal Assist and 20 MPH on Throttle
Stem
Threadless, 31.8mm, 7 Degree Rise
Handlebar
Aluminum 31.8mm, 680mm
Fork
Coil Spring Suspension, Thru-axle, 65mm travel with lockout
Seat
31.8 mm Quick Release
Seatpost
Aluminum Alloy, 27.2mm, 2-Bolt Clamp
Grip
Ergonomic Comfort
Crankset
170mm w/ 46 T
Pedals
9/16" Alloy Platform
Pedal Assist System - PAS
5 Levels
Chain
122 Link, 8 Speed
Shifters
8 Speed
Saddle
Aventon by Velok
Headset
Sealed Bearing Headset
Derailleur : Rear
8 Speed
Hub : Front
36H Disc Thru-axle Front, Nutted Rear
Spoke
Black Stainless 13G Front / 12G Rear
Cassette
12-32T, 8 Speed Cassette
Bottom Bracket
Square Taper, Sealed, Torque Sensor
Stand
Included, Rear Mount
Motor Details
750W (Peak) 500W (Sustained) Brushless Rear Hub Motor
Range
Up To 96 km
Display
LCD Smart Easy Read Display with Backlight, Colorful screen with app
Electricals
Battery
Removable Internal Lithium-ion 48V, 14Ah (672Wh)
Charger
48V 3 Amp Fast Charger, 4-5 Hour Charging
Brakes
Front Brake
Hydraulic Disc Brakes, 180mm Rotors
Chassis and Suspension
Frame
6061 Double-Butted Aluminum Alloy with Internal Battery
Tyres
Front Tyre
27.5” x 2.1” Hybrid Tires, Reflective Sidewalls
Tube
Butyl Rubber, Schrader Valve
Dimensions
Height
662mm
Wheelbase
1097 mm
Weight
24kg
Additional Details
Throttle: Throttle on demand - Throttle from a complete stop
SENSORS: Torque Sensor
Top Tube Length: 579mm
Reach: 364mm
Head Tube Length: 150mm
Standover Height: 662mm
Min Saddle Height: 835mm
Max Saddle Height: 1015mm
