Bee Pathfinder Step-Thru Electric Bicycle

Price, features and specs

Rate Bee Pathfinder Step-Thru:
4.2/5 (5 votes)
Bee Pathfinder Step-Thru Price $ 1699 [Chicago, United States]

The given price can change depending on the colour, accessories and other features.

Country, City Showroom Price On Road Price
United States, Chicago $ 1699 --
Features
- The headlight is bright enough to see the road clearly
- The wider bike seat helps a lot with easing the pressure and makes ride more comfortable
- The fenders are installed both front and rear
Similar Bicycles
Colours

Aurora
Black

Technical Specifications
Vehicle TypeBicycle
FuelElectric
Maximum Power750 W
Load Carrying CapacityPayload Capacity : 350 lbs
Stem50mm + 30º (15mm rise)
HandlebarCustom formed aluminum, 700mm wide, 4" rise
ForkHydraulic fork, 120mm travel, with lockout and preload adjustment; 245mm steerer tube
Seatpostsuspension seat post 350mm x 31.8mm
GripDurable imitation leather ergo
Crankset48T, 170mm forged alloy, dual-sided aluminum bash-guard
PedalsCrMo axle, forged aluminum platform with reflectors, standard 9/16" x 20 TPI threading
Pedal Assist System - PASIntelligent 5 level pedal assist with 12 cadence sensor
ChainZ7
ShiftersShimano SL-TX50-7R thumb shifter, 7-speed
Gear1 x 7-speed
SaddlePlush with lifting handle
HeadsetSemi-integrated, 1-1/8" straight steerer tube
Derailleur : Front7-Speed Shimano Tourney
Derailleur : Rear7-Speed Shimano Tourney
Spoke12-gauge stainless steel, black
StandHeavy-duty aluminum with wide plastic foot
Motor Details
750W (continuous) 1100W (peak) brushless geared hub motor with 80 Nm of torque, 5:1 planetary gear reduction
Range
40 - 65 miles
Display
Color LCD with charge indicator, speedometer, odometer, trip odometer, pedal assist level, watt-meter, and more
Electricals
Battery48V(912-960Wh) Lithium-ion battery, rated for 900 charge cycles
Charger48V, 3 A smart charger, operates on 100V-240V AC power outlets
Controller48V, 22A
Head Lamp300 lm LED headlight
Tail LampIntegrated signal taillight with brake light
Brakes
Front BrakeDidor
Rear BrakeDidor
Brake LeverAluminum alloy comfort grip levers with motor cutoff switch and integrated bell
Chassis and Suspension
Frame6061 aluminum
Tyres
Wheels / RimRims : Double wall, 36H
Front Tyre26" x 4", TPI:60
Rear Tyre26" x 4", TPI:60
Additional Details
Throttle : Half twist throttle
Wiring : Water resistant connectors and wiring harness
Brake Calipers : Didor
Brake Pad Material : Sintered metal
Fenders : Half coverage front and rear
Freewheel : Shimano Tourney MF-TZ500 7-Speed 14-28 Tooth
Racks : Included, 60LB Max Payload
