Price, review, features and specs
Rate IDEAL Prisma E810FX Wave 29:
IDEAL Prisma E810FX Wave 29 Price
£
4290
[Doncaster, United Kingdom]
The given price can change depending on the colour, accessories and other features.
| Country, City |
Showroom Price |
On Road Price |
| United Kingdom, Doncaster |
£ 4290 |
-- |
Buy new IDEAL Prisma E810FX Wave 29
Book a Test Drive through Bikes4Sale and we will try to get you the best offer for IDEAL Prisma E810FX Wave 29.
For Exciting Offers, Book a Test Drive
Technical Specifications
| Vehicle Type | Bicycle |
| Fuel | Electric |
| Maximum Torque | 85 Nm |
| Stem | Ergotec Crab 2 aluminum, 31.8 mm, safety level 4 |
| Handlebar | Ergotec Low Riser aluminum bar, 720 mm, safety level 4 |
| Fork | RST AERIAL TNL, 100 mm, 32 mm, Air, Lock Out |
| Seatpost | Ergotec Atar aluminum, 30.9 mm, safety level 4 |
| Crankset | Shimano STEPS FC-EM600, 38T |
| Chain | Shimano CN-E6090-10 |
| Shifters | Shimano STEPS SW-E7000-L switch // Shimano Deore SL-M4100-R |
| Saddle | Selle Royal Premium, New Essenza, H / D Moderate |
| Derailleur : Rear | Shimano Deore RD-M5120 SGS Shadow Plus |
| Hub : Front | Shimano HB-M3050 |
| Hub : Rear | Shimano FH-M3050 |
| Cassette | Shimano CS-M4100-10, 11-42T |
| Sprocket | Shimano CS-M4100-10, 11-42T |
| Stand | Atran Rex-HV rear kickstand |
| Motor Details |
|---|
| Shimano STEPS center drive unit DU-EP800, 36V, 250W, 85Nm, sports |
| Display |
|---|
| Shimano STEPS display SC-E6100 |
| Electricals |
|---|
| Battery | Shimano STEPS battery (down tube) BT-E8036, 36V, 14Ah, 630Wh |
| Head Lamp | Herrmans H-Black MR8, 50Lux |
| Tail Lamp | AXA Blue Line 2 |
| Brakes |
|---|
| Front Brake | Shimano BR-MT410 / BL-MT401 hydraulic disc brakes 180 mm Sensor Rotor |
| Rear Brake | Shimano BR-MT410 / BL-MT401 hydraulic disc brakes 180 mm Sensor Rotor |
| Chassis and Suspension |
|---|
| Frame | eAdventure 29, AL6061-T4 / T6, Shimano STEPS, hydroforming, internal brake & gear cables, fully integrated battery |
| Tyres |
|---|
| Wheels / Rim | Mach1 670, 584-21 |
| Front Tyre | Schwalbe 60-622 (29x2.35), Johnny Watts |
| Rear Tyre | Schwalbe 60-622 (29x2.35), Johnny Watts |
| Additional Details |
|---|
Size : 50/54 cm
Mudguards : SKS PET A65R, 65 mm
Carrier : ID-Project, Racktime Snapit System, integrated (IMM) |
