Trellis, high-tensile steel with Swingarm Mounting Plate
Front Suspension
43 mm inverted fork with KECS-controlled rebound and compression damping, manual spring preload adjustability, and top-out springs
Wheel travel front : 120 mm
Rear Suspension
New Uni Trak, BFRC lite gas-charged shock with piggyback reservoir, KECS-controlled compression and rebound damping, and electronically adjustable spring preload
Wheel travel rear : 139 mm
Tyres
Wheels / Rim
Alloy
Front Tyre
120/70ZR17M/C (58W)
Rear Tyre
190/55ZR17M/C (75W)
Dimensions
Length
2175mm
Width
790mm
Height
1260mm
Seat Height
835 mm
Wheelbase
1480 mm
Kerb Weight
267 kg
Ground Clearance
130 mm
Fuel Tank Capacity
19 litres
Additional Details
Valve system : DOHC, 16 valves
Fuel consumption : 5.4 l/100 km
CO2 emission : 128 g/km
Primary Reduction Ratio : 1.480 (74/50)
Gear Ratios 1st : 3.077 (40/13)
Gear Ratios 2nd : 2.429 (34/14)
Gear Ratios 3rd : 2.045 (45/22)
Gear Ratios 4th : 1.727 (38/22)
Gear Ratios 5th : 1.524 (32/21)
Gear Ratios 6th : 1.348 (31/23)
Final reduction ratio : 2.444 (44/18)
Trail : 103 mm
