43 mm inverted fork with stepless rebound damping (right side) and spring preload adjustability (Versys 1000) 43 mm inverted fork with KECS-controlled rebound and compression damping, manual spring preload adjustability and top-out springs (Versys 1000 SE)
Wheel travel front : 150 mm
Rear Suspension
Horizontal Back-link, gas-charged, with stepless rebound damping and remote spring preload adjustability (Versys 1000) Horizontal Back-link, BFRC lite shock, KECS-controlled compression damping, rebound damping and spring preload adjustability (Versys 1000 SE)
Wheel travel rear : 152 mm
Tyres
Wheels / Rim
Alloy
Front Tyre
120/70ZR17M/C (58W)
Rear Tyre
180/55ZR17M/C (73W)
Dimensions
Length
2270mm
Width
950mm
Height
1490mm
Seat Height
840 mm
Wheelbase
1520 mm
Kerb Weight
255 kg
Ground Clearance
150 mm
Fuel Tank Capacity
21 litres
Additional Details
Valve system : DOHC, 16 valves
Power down kit 85 kW : Available
CO2 emission : 128 g/km
Fuel consumption 85 kW kit : 5.5 l/100 km
CO2 emission 85 kW kit : 128 g/km
Primary Reduction Ratio : 1.627 (83/51)
Gear Ratios 1st : 2.692 (35/13)
Gear Ratios 2nd : 1.950 (39/20)
Gear Ratios 3rd : 1.529 (26/17)
Gear Ratios 4th : 1.304 (30/23)
Gear Ratios 5th : 1.136 (25/22)
Gear Ratios 6th : 0.958 (23/24)
Final reduction ratio : 2.867 (43/15)
Trail : 106 mm
Steering angle, left / right : 34˚/34˚
