Kellys Theos I50 Dark 29/27.5 630WH

Price, review, features and specs

Rate Kellys Theos I50 Dark 29/27.5 630WH:
3.5/5 (4 votes)
Add To Compare
Write a Review
Kellys Theos I50 Dark 29/27.5 630WH Price

Not Available

Buy new Kellys Theos I50 Dark 29/27.5 630WH

Book a Test Drive through Bikes4Sale and we will try to get you the best offer for Kellys Theos I50 Dark 29/27.5 630WH.

For Exciting Offers, Book a Test Drive
8071
Kellys Theos I50 Dark 29/27.5 630WH
Kellys Theos I50 Dark 29/27.5 630WH
Kellys Theos I50 Dark 29/27.5 630WH
Kellys Theos I50 Dark 29/27.5 630WH
Kellys Theos I50 Dark 29/27.5 630WH
Technical Specifications
Vehicle TypeBicycle
FuelElectric
Speed10
StemKLS Alm/En 50 - diam 28.6 mm / bar bore 31.8 mm / length 60 mm
HandlebarKLS Alm/En 70 RiseBar - diam 31.8 mm / rise 25 mm / width 760 mm
ForkROCK SHOX 35 GOLD RL (29) Boost, 160 mm, DebonAir / Motion Control / Maxle Stealth 15 mm thru axle
SeatpostKS RAGE-I Remote Telescopic - diam 31.6 mm / length 442 mm, travel 125 mm (S), 150 mm (M - XL)
GripKLS Poison OneLockon
CranksetSHIMANO E8000 (38T) - length 170 mm
PedalsPlastic
ChainKMC e10T (116 links)
ShiftersSHIMANO Deore M4100-R Rapidfire Plus (I-Spec EV)
Saddlefi´zi:k Taiga S-alloy rails
Derailleur : RearSHIMANO Deore M5120 (direct mount)
Hub : FrontSHIMANO MT400-B Disc Center Lock (15 x 110 mm / 12 x 148 mm / 32 holes)
Hub : RearSHIMANO MT400-B Disc Center Lock (15 x 110 mm / 12 x 148 mm / 32 holes)
Spokestainless steel black
CassetteSHIMANO CS-HG4100-10 (11-46T)
SprocketSHIMANO CS-HG4100-10 (11-46T)
Motor Details
SHIMANO STEPS E7000, 36V
Display
SHIMANO SC-E5000 cycle computer with assist switch
Electricals
BatteryKELLYS Re-Charge Li-ion internal 630Wh / capacity 17.5Ah
Brakes
Front Brake203 mm, SHIMANO Deore (021) MT410 Hydraulic Disc
Rear Brake203 mm, SHIMANO Deore (021) MT410 Hydraulic Disc
Brake LeverSHIMANO Deore (021) BL-M4100
Chassis and Suspension
FrameKELLYS e-FRAME Allmountain, Uni-Body Integrated Design / Four-bar link, 150 mm rear travel, tapered HT, mullet 29 / 27.5+ wheelset, 12 x 148 mm Boost thru axle
Tyres
Wheels / RimKLS Valor 3 Disc 622 x 30 front / 584 x 30 rear (32 holes)
Front TyreSCHWALBE Nobby Nic Performance 65-622 (29 x 2.60) ADDIX
Rear TyreSCHWALBE Nobby Nic Performance 70-584 (27.5 x 2.80) ADDIX
Dimensions
Length x Width x Height-- x -- x -- mm
Additional Details
Rear Shock : ROCK SHOX Deluxe Select R, DebonAir / Trunnion mount (205 x 65 mm)
Frame Size : M / L / XL
Head Parts : FSA 1.5 integrated
Thru Axle : ROCK SHOX Maxle Stealth 15 x 110 mm front / NOVATEC 12 x 148 mm rear
