Price, review, features and specs
Rate Marin Nail Trail E2:
The given price can change depending on the colour, accessories and other features.
Country, City |
Showroom Price |
On Road Price |
United States, Sparks |
$ 4409 |
-- |
Buy new Marin Nail Trail E2
Book a Test Drive through Bikes4Sale and we will try to get you the best offer for Marin Nail Trail E2.
For Exciting Offers, Book a Test Drive
The Hub-Co100 Country Center Dr
Suite F
Colorado United States
Contact Dealer Biking Roots3315 Spring Cypress Rd
Suite 5E
Texas United States
Contact Dealer
Features
- Shimano Steps Electric Assist
Technical Specifications
Vehicle Type | Bicycle |
Fuel | Electric |
Stem | 35 mm Marin 3D Forged Alloy |
Handlebar | Marin Mini-Riser, 6061 Double Butted Aluminum, 780mm Width, 28mm rise, 5º Up, 9º Back |
Fork | RockShox Revelation RC 27.5+, 140 mm Travel, Compression and Rebound Adjustment, Solo Air Spring, 110 x 15 mm Boost Spacing, Maxle Stealth, 51 mm Offset |
Seatpost | 30.9 mm X-Fusion Manic, 1x Plastic Remote, Size S 120 mm Travel, All Other Sizes: 150 mm Travel, |
Grip | Marin Single Clamp Locking |
Crankset | Shimano FC-E8050, Hollowtech II, 38T, Boost Spacing |
Pedals | Nylon Platform |
Chain | Sram PC-EX1 |
Shifters | Sram EX1, 8 speed
Shift Lever : Sram EX1, 8 speed |
Saddle | Marin Speed Concept |
Headset | FSA No 57E, Semi-Sealed Cartridge Bearings, 1 1/8" x 1 1/2” |
Derailleur : Rear | Sram EX1, 8 Speed |
Hub : Front | Forged Alloy, 110x15mm, 6-Bolt Disc, 32H |
Hub : Rear | Forged Alloy, 148x12mm, Quad Sealed Bearings, 6-Bolt Disc, 32H |
Spoke | 14g Black Stainless Steel |
Cassette | Sram EX1, 11-48T |
Motor Details |
Shimano STEPS E8000 |
Electricals |
Battery | 500Wh Shimano E8010 |
Brakes |
Front Brake | Shimano MT520 4 Piston Hydraulic Disc, 203mm Rotor |
Rear Brake | Shimano MT520 4 Piston Hydraulic Disc, 203mm Rotor |
Brake Lever | Shimano MT501 Hydraulic |
Chassis and Suspension |
Frame | Series 3 E 6061 Aluminim, 27.5+ Wheels, Post mount, Forged Drop Outs, 148x12 Thru Axle |
Tyres |
Wheels / Rim | Marin Aluminum Double Wall, 38 mm Inner, Pinned Joint, Disc Specific, Tubeless Compatible |
Front Tyre | Vee Tire, Crown Gem 27.5x2.8", Dual Control Compound, Synthesis Sidewall, Folding Bead, Tubeless Compatible |
Rear Tyre | Vee Tire, Crown Gem 27.5x2.8", Dual Control Compound, Synthesis Sidewall, Folding Bead, Tubeless Compatible |
Dimensions |
Length x Width x Height | -- x -- x -- mm |
Additional Details |
Bolt-on Thru-Axle |
