MERIDA eBig.Nine LTD Electric Bicycle

Price, features and specs

Rate MERIDA eBig.Nine LTD:
4.0/5 (4 votes)
MERIDA eBig.Nine LTD Price

Not Available

Features
- Lightweight aluminium frame with 29er wheels
- Long-lasting 630 Wh battery
- Comfort and control enhancing suspension fork
- Powerful and refined Shimano EP8 assistance
- Confidence inspiring mountain bike handling
- Comes fully equipped with lights, kickstand, rack and mudguards
Colours

COOL GREY (RED/BLACK)

Technical Specifications
Vehicle TypeBicycle
FuelElectric
DrivetrainDrive Unit : Shimano EP8
85 Nm
StemMERIDA EXPERT CC
Material: aluminium
31.8mm diameter
5° stem angle
80 mm-M, 90 mm-L, 100 mm-XL
HandlebarMERIDA EXPERT CC
Material : Aluminium
720mm width
10mm rise
ForkSR Suntour XCM32 DS
Coil
100mm
Tapered
47mm fork offset
29x2.4" max wheelsize
SeatpostMERIDA EXPERT
Material: aluminium
30.9mm diameter
15mm setback
GripMERIDA EXPERT EC
CranksetShimano FCEM600
165 mm
PedalsVP VPE-537
ChainKMC e9s
ShiftersShimano Alivio
SaddleMERIDA COMP SL
V-mount
HeadsetMERIDA 2341
Derailleur : RearShimano Alivio M3100
SGS
Hub : FrontShimano MT400 / Shimano MT400-B
110x15mm width front hub
32 spoke holes
Centerlock
Hub : RearShimano MT400 / Shimano MT400-B
148x12mm width rear hub
36 spoke holes
Centerlock
SpokeBlack stainless
StandMassload CL-KA98
Display
Shimano SC-E5003A
Electricals
BatteryShimano E8016
630Wh
Battery Lock : Abus key
Head LampDlight CG-119PG
StVZO
Tail LampDlight CG-404RG
STVZO
Brakes
Front BrakeTektro M275
2 piston
Rear BrakeTektro M275
2 piston
Chassis and Suspension
FrameeBIG.NINE LITE
Material: aluminium
29x2.35" without fender max./ 29"x2.25" with fender max. wheelsize
148x12mm axle standard
External
FRAME SIZE : M, L, XL
Tyres
Wheels / RimMERIDA COMP CC
20mm inner width
Material: aluminium
Front TyreMaxxis Ikon
29x2.2"
Rear TyreMaxxis Ikon
29x2.2"
Dimensions
Weight140 kg
Additional Details
Rotors : Shimano RT10
180 mm
Seat Clamp : MERIDA EXPERT
ChainWheel : Shimano CRE70-B
34 teeth
FreeWheel : Shimano HG200
11-36 teeth
9 speed
Axles : MERIDA COMP TR
Including removeable lever, 6/4mm allen key
