MERIDA eSpresso 575 EQ Electric Bicycle

Price, features and specs

Rate MERIDA eSpresso 575 EQ:
3.6/5 (5 votes)
MERIDA eSpresso 575 EQ Price

Not Available

Features
- Smooth, refined Shimano E6100 drive unit
- Low maintenance Shimano Nexus hub gearing
- Fast-rolling 700c wheels and comfortable, grippy 50 mm tyres
- Lightweight frame with internally mounted 750 Wh battery
- Fully equipped with guards, lights, lock, rack and kickstand
- Low step-through frame option available
Colours

MATT GREEN (BLACK)
SILK STEEL BLUE (GUNMETAL GREY)
MATT DARK SILVER/BLACK

Technical Specifications
Vehicle TypeBicycle
FuelElectric
DrivetrainShimano E6100
60Nm
StemMERIDA EXPERT CT
Material: aluminium
31.8mm diameter
Adjustable
90 mm-XS/S/M, 110 mm-L/XL
HandlebarMERIDA EXPERT TK
Material: aluminium
660mm width
15mm rise
ForkSR Suntour NEX E25
Coil
63mm suspension travel
700x52C max wheelsize
SeatpostMERIDA EXPERT CC
Material: aluminium
34.9mm diameter
0mm setback
GripMERIDA EXPERT TK
CranksetShimano FC-EM600
170 mm
PedalsVP VPE-891
ChainKMC e10S EPT
ShiftersShimano Deore M4100
SaddleMERIDA EXPERT TK
V-mount
HeadsetMERIDA 8156
Derailleur : RearShimano Deore M5120
SGS
Hub : FrontShimano TX505 / Shimano MT400
100x9mm width front hub
32 spoke holes
Centerlock
Hub : RearShimano TX505 / Shimano MT400
142x12mm width rear hub
36 spoke holes
Centerlock
SpokeBlack stainless
StandMassload CL-KA98
Display
Shimano SC-E5000A
Electricals
BatterySimplo Internal Battery
750Wh
BATTERY LOCK : Abus Key
Head LampHerrmans H-Black MR4 E
STVZO
Tail LampSpanninga Commuter Glow XE
STVZO
Integrated in MERIDA MIK HD carrier
Brakes
Front BrakeShimano MT200
2 piston
Rear BrakeShimano MT200
2 piston
Chassis and Suspension
FrameeSPRESSO LITE IV
Material: aluminium
700x50C (with fender) max. wheelsize
142x12mm axle standard
Intube
FRAME SIZE XS, S, M, L, XL
eSPRESSO L XS(43L)-S(47L)-M(51L)-L(55L)
Tyres
Wheels / RimMERIDA COMP TK
20mm inner width
Material: aluminium
Front TyreContinental Ride Cruiser
622-50
Wire
Reflecting line
Rear TyreContinental Ride Cruiser
622-50
Wire
Reflecting line
Dimensions
Weight150 kg
Additional Details
Rotors : Shimano RT10
180 mm
Seat Clamp : MERIDA EXPERT
ChainGuard : Sunnywheel SW-CG-173A
ChainWheel : Shimano CRE61
38 teeth
FreeWheel : Shimano M4100
11-46 teeth
10 speed
Axles : MERIDA COMP TR
including removeable lever, 6mm allen key
Carrier : MERIDA MIK HD
Spring clip
Spanninga rear light
FENDER : Sunnywheel SW-FA311-60E1 (MSB)
FRAME LOCK : Abus 5650 LH-3 lock
