Price, features and specs
Rate MERIDA eSpresso City 775 EQ:
MERIDA eSpresso City 775 EQ Price
€
3899
[Berlin, Germany]
The given price can change depending on the colour, accessories and other features.
Country, City
Showroom Price
On Road Price
Germany, Berlin
€ 3899
--
Features
- Extra low step-through ENERGY CRADLE frame design
- Trekking dedicated Shimano E6100 drive unit
- Fully equipped with guards, lights, lock, rack and kickstand
- Internally mounted 750 Wh battery
- Low maintenance Shimano hub gearing
- Fast rolling 700c wheels and comfy 50 mm tyres with reflective strip
Colours
SILK TEAL-BLUE (LIME)
MATT DARK SILVER (BLACK)
Technical Specifications
Vehicle Type Bicycle Fuel Electric Drivetrain Shimano E6100
60Nm Stem MERIDA EXPERT TK
Material: aluminium
31.8mm diameter
Adjustable
65 mm-XS/S/M, 90 mm-L/XL Handlebar MERIDA EXPERT TK
Material: aluminium
640mm width
35mm rise Fork SR Suntour NEX E25
Coil
63mm suspension travel
700x52C max wheelsize Seatpost MERIDA EXPERT TK
30.9mm diameter
15mm setback
40mm seatpost suspension travel Grip MERIDA EXPERT TK Crankset Shimano FC-EM600
165 mm Pedals VP VPE-891 Chain KMC Z1eHX EPT Shifters Shimano SW-E6010-R Saddle MERIDA EXPERT TK
V-mount Headset MERIDA 8152 Hub : Front Shimano M4050 / Shimano Nexus Inter-5E
100x9mm width front hub
32 spoke holes
Centerlock Hub : Rear Shimano M4050 / Shimano Nexus Inter-5E
135x9mm width rear hub
36 spoke holes
Centerlock Spoke Black stainless Stand Atranvelo 1219-PC-7
Electricals Battery Simplo Internal Battery
750Wh
BATTERY LOCK : Abus Key Head Lamp Herrmans H-Black MR4 E
STVZO Tail Lamp Spanninga Commuter Glow XE
STVZO
Integrated in MERIDA MIK HD carrier
Brakes Front Brake Shimano MT402-3A
2 piston Rear Brake Shimano MT402-3A
2 piston
Chassis and Suspension Frame eSPRESSO CITY LITE II HG
Material: aluminium
700x50C max. wheelsize
135x9mm axle standard
Internal
Hub-gear dropout
FRAME SIZE : XS, S, M, L, XL
Tyres Wheels / Rim MERIDA COMP TK
20mm inner width
Material: aluminium Front Tyre Continental Contact Cruiser
622-50
Wire
Reflecting line Rear Tyre Continental Contact Cruiser
622-50
Wire
Reflecting line
Additional Details
Rotors : Shimano RT30 / Shimano RTEM300
180 mm
Seat Clamp : MERIDA EXPERT
ChainGuard : Sunnywheel SW-CG-173A
ChainWheel : Shimano CRE61
38 teeth
FreeWheel : Shimano CS-C7000
30 teeth
Carrier : MERIDA MIK HD
Spring clip
Spanninga rear light
FENDER : Sunnywheel SW-FA311-60E1 (MSB)
FRAME LOCK : Abus 4650 XL
