Schindelhauer Emily

Price, review, features and specs

Rate Schindelhauer Emily:
4.0/5 (2 votes)
Add To Compare
Write a Review
Schindelhauer Emily Price 4395 [Berlin, Germany]

The given price can change depending on the colour, accessories and other features.

Country, City Showroom Price On Road Price
Germany, Berlin € 4395 --
Buy new Schindelhauer Emily

Book a Test Drive through Bikes4Sale and we will try to get you the best offer for Schindelhauer Emily.

For Exciting Offers, Book a Test Drive
By submitting, you agree to our Terms & Conditions.
1483
Features
- Motor and light control at the touch of a button on the frame or app
Similar Bicycles
Colours

Mineral Grey

Technical Specifications
Vehicle TypeBicycle
FuelElectric
Maximum Power250 W
Maximum Torque40 NM
Load Carrying CapacityPermitted total weight : 130 kg (bike + rider + luggage)
Transmission6 or 9-speed Pinion C-Line gearbox
DrivetrainGates Carbon Drive CDX, front 39T, rear 34T/28T, timing belt 118T/115T
Top Speed25 kmph
StemSatori - Stealth, aluminum
HandlebarSchindelhauer - City , aluminum
ForkHydroformed aluminum fork (tapered)
SeatpostSchindelhauer
GripSchindelhauer
CranksetPinion
PedalsVP - Plastic with GripTape, sealed bearings
SaddleSchindelhauer
SpokeSapim spokes, 3-way and 1-way crossed spokes
Bottom BracketPinion
StandSide stand
Motor Details
Mahle-ebikemotion – Motor HUB Drive M1
Electricals
BatteryMahle-ebikemotion - Intube battery with approx. 250 Wh energy content
Head LampLightSkin Ultra-Mini-Light U2E
Tail LampILU jr.
Brakes
Front BrakeShimano – MT200 disc brake (hydraulic) 160mm
Rear BrakeShimano – MT200 disc brake (hydraulic) 160mm
Chassis and Suspension
FrameAluminum (AL6061-T6)
Size : S, M, L
Tyres
Wheels / RimAlexrims - DP23 27.5" rims
Front TyreWTB - Horizon 47-584, with reflective strips
Rear TyreWTB - Horizon 47-584, with reflective strips
Dimensions
Weight18.3 kg
Additional Details
Tax rate : Acros-ICR 1.5''
On-board computer : Mahle ebikemotion – iWoc ONE with Bluetooth and ANT+
Circuit : Pinion - gear unit, C-Line 6-/9-speed (XR)
Impellers : Schindelhauer - high flange front wheel hub disc, ebikemotion motor HUB Drive M1
Fenders : Curana – Apollo (Aluminum Profile Fenders)
Porter : Schindelhauer – aluminium, fixed to the frame, with Vario Strap system, suitable for Ortlieb Rack-Lock
Other specifications : Bottle or lock holder assembly and frame lock possible , Child seat assembly is possible
