Tern HSD P9

Price, review, features and specs

Max speed 25 kph (EU)
Max speed 20 mph (US)

Rate Tern HSD P9:
3.5/5 (2 votes)
Add To Compare
Write a Review
Tern HSD P9 Price $ 3199 [Chicago, United States]

The given price can change depending on the colour, accessories and other features.

Country, City Showroom Price On Road Price
United States, Chicago $ 3199 --
United States, Los Angeles $ 3199 --
United States, New York $ 3199 --
United States, San Diego $ 3199 --
Buy new Tern HSD P9

Book a Test Drive through Bikes4Sale and we will try to get you the best offer for Tern HSD P9.

For Exciting Offers, Book a Test Drive
2628
Colours

Red
Dune

Tern HSD P9
Tern HSD P9
Tern HSD P9
Tern HSD P9
Tern HSD P9
Tern HSD P9
Tern HSD P9
Technical Specifications
Vehicle TypeBicycle
FuelElectric
StemTern Andros (G2), adjustable, forged construction, patented technology
HandlebarTern Sweep, 6061-AL, Tern Andros adapted
ForkSuntour custom for Tern, Chromoly steerer, 32 mm stanchions, Thru-axle, EFBE tested for 170 kg
SeatpostTern Telescope, 34.9/30.9 mm, 2014-AL
GripErgon
CranksetTern HSD custom
PedalsUrban with non-slip surface
Chain9 spd, DHT for eBike, GST corrosion resistant coating
ShiftersShimano Alivio, 1 x 9 spd, trigger
SaddleTern HSD
Derailleur : RearShimano Alivio Shadow
Hub : FrontShimano disc
Hub : RearNovatec, Thru-axle, sealed bearings
SpokeStainless steel
CassetteShimano 11-32T, 9 spd
Motor Details
Bosch Active Line Plus (Gen 3)
Range
42 -110 km (26-69 mi)
Display
Bosch Purion, 4 mode selectable, walk assist
Electricals
BatteryBosch PowerPack 400
ChargerAluminum
Head LampHerrmans H-Trace, for eBike
Tail LampSKS, stainless hardware
Brakes
Front Brake180 mm rotor ,Shimano, hydraulic disc
Rear Brake160 mm rotor , Shimano, hydraulic disc
Brake LeverShimano, hydraulic disc
Chassis and Suspension
FrameTern HSD, 6061-AL, patented design, Tern sliding dropouts, EFBE Tri-Test approved: 170 kg
Tyres
Wheels / RimSize : 20" wheels
Type : Tern Atlas H, cargo wheel
Rims : Tern Atlas H, wide 35 mm
Front TyreSchwalbe Big Apple, 55-406, puncture protection, Reflex
Rear TyreSchwalbe Big Apple, 55-406, puncture protection, Reflex
Dimensions
Length x Width x Height-- x -- x -- mm
Weight25.7 kg
Accessories
BELL : SKS Chainblade
CHAINGUARD : Ursus, rear mount
KICKSTAND : Combo Mount
FENDERS : Atlas H rack, Atlas Rack Mount, 6 point mounting
RACK(S) : ABUS 5650L, keyed-alike with Bosch battery
Additional Details
SPEEDS : 1 x 9
FOLDING SIZE : 163 x 40.5 x 86 cm (64" x 15.9" x 34")
FOLDING TIME : 5 sec
FRAME SIZES : One size
GEAR INCHES : 33" - 97" (2.65 - 7.72 m)
DISTANCE: SEATPOST TO HANDLEBAR : Min: 490 mm (19.3"); Max: 590 mm (23")
DISTANCE: SADDLE TO PEDAL : Min: 690 mm (27.2") Max: 1050 mm (41.3")
SUGGESTED RIDER HEIGHT : 150 - 195 cm (4'11" - 6'5")
MAX GROSS VEHICLE WEIGHT : 170 kg (374 lbs)
MAX RIDER WEIGHT : 120 kg. (264 lbs.)
SHIFTER CABLE & HOUSING : Jagwire LEX-SL, slick treatment, alloy ferrules
HANDLEPOST : Tern Physis 3D (G2), 3D forged, 5 patented technologies, 12°, 290 mm
SEATPOST CLAMP : Tern Collar, 6061-AL, 2pc
