Urban Arrow Cargo L Bicycle: Price, Review, Specs and Features

Price, review, features and specs

The Cargo L provides five choices that are the flatbed, the Toploader, the customizable Flightcase, the aluminum box and the Craft.
Flatbed L Cargo Line Disc Zee 500Wh Price : € 4.590

Rate Urban Arrow Cargo L:

3.0/5 (2 votes)

Add To Compare
Write a Review

Urban Arrow Cargo L Price € 4090 [Almere, Netherlands]

The given price can change depending on the colour, accessories and other features.

Country, City	Showroom Price	On Road Price
Netherlands, Almere	€ 4090	--
Netherlands, Amsterdam	€ 4090	--
Netherlands, Rotterdam	€ 4090	--
Netherlands, The Hague	€ 4090	--

Buy new Urban Arrow Cargo L

Book a Test Drive through Bikes4Sale and we will try to get you the best offer for Urban Arrow Cargo L.

For Exciting Offers, Book a Test Drive

Picture Gallery

Black

Features

- Bike lane fit
- Easily transport large volumes while maintaining flexibility

Similar Bicycles

Beta eKinder Race 20 Compare

Beta eKinder Race 18 Compare

Beta ekinder Race 16 Compare

Canyon Grail CFR Di2 Compare

Trek Checkpoint SLR 9 AXS Compare

Trek Fuel EXe 9.9 XX AXS T-Type Compare

Colours

Black
White

Urban Arrow Dealers

BiciCare

Willem de Zwijgerlaan 49 Netherlands

Contact Dealer

Beekhoven Bikes

Draaierweg 16 Netherlands

Contact Dealer

More Dealers

View all Urban Arrow Showrooms

View All Showrooms

Technical Specifications

Vehicle Type	Bicycle
Fuel	Electric
Stem	TranzX JD-ST17-2 black 1-1/8 25,4 110mm
Handlebar	Ergotec Moon cruiser 25,4 black
Fork	Spinner 300 suspension fork
Seatpost	Satori Trident 31,6 400mm black
Grip	Ergon GC10
Crankset	Lasco EB05 BNI 170 mm
Pedals	C558
Shifters	Enviolo CA - Cargo
Saddle	Selle Royal Rio Plus
Hub : Front	Enviolo Cargo, 36H
Hub : Rear	Shimano HB-M525A, 36H

Display
Bosch Purion

Electricals
Battery	Bosch 500 Wh
Head Lamp	Spanninga Axendo 40
Tail Lamp	Spanninga Plateo XE 6V-36V

Brakes
Front Brake	Shimano Deore M6000 (caliper); RT-66 203mm (disc); Elvedes metal pads 6894S
Rear Brake	Shimano Deore M6000 (caliper); RT-66 203mm (disc); Elvedes metal pads 6894S

Tyres
Wheels / Rim	Rear Rim : Ryde Andra 40 Double wall 26" x 1.75; Sapim spokes (13G) Front Rim Ryde Andra 40 Double wall 20" x 1.75; Sapim spokes (14G)
Front Tyre	Schwalbe Big Ben Plus 55-559
Rear Tyre	Schwalbe Big Ben Plus 55-406

Dimensions
Weight	50 kg

Additional Details
Drive line: Chain, KMC e101 /2*1/8 102L Steering rod : UA cargo steering rod Rear sprocket : Enviolo 17T Front sprocket : Lasco 38T, 4 hole, 104BCD Chainguard : Hebie chainglider front 38T, 350R NV16, 16-22T for Enviolo Valve : Schrader Rear fender : SKS 65mm 26" Black matte Front fender : SKS 65mm 20" Black matt
