SR Suntour, NEX E25, Steel spring, 63 mm travel, Steel steerer tube 1 1/8" - 1 1/2" tapered, Quick release 100 mm
Seatpost
XLC, Aluminium, Patent, 31.6 mm
Grip
XLC, Comfort bo3
Pedals
VP, E461, Aluminium, with Reflector
Chain
KMC, e10S
Shifters
Shift Lever : Shimano, Altus M315, Rapidfire
Saddle
Selle Royal, Essenza
Headset
Feimin, A-Head Tapered, Aluminium, CartridgeCane Creek, Viscoset, Aluminium
Derailleur : Rear
Shimano, Acera M360
Hub : Front
Alu hub
Hub : Rear
Alu hub
Spoke
Sapim, Leader
Chainrings
Steel, 38 teeth
Sprocket
SunRace, CSM55, 11 - 34 teeth
Bottom Bracket
Integrated in the motor
Stand
Ursus, Mooi, Rear stand
Motor Details
Yamaha, PW-ST System, 250 Wh
Display
Yamaha, Side Switch, 1.7" LCD, 7 functions
Electricals
Battery
Yamaha, InTube, 630 Wh
Head Lamp
Herrmans, H-Black MR-GO
Tail Lamp
AXA, Juno Ebike
Brakes
Front Brake
Alhonga, HT474, Hydraulic disc brakes
Rear Brake
Alhonga, HT474, Hydraulic disc brakes
Brake Lever
Alhonga, HT474, Aluminium
Chassis and Suspension
Frame
Winora, Aluminium 6061, Yamaha InTube 630, HD Interface, Aluminium 6061
Tyres
Wheels / Rim
Schurmann, Yak25, With Eyelets, Double Wall, Aluminium
Front Tyre
Schwalbe, Al Grounder Performance, 60-584, 27.5 x 2.4 inch
Rear Tyre
Schwalbe, Al Grounder Performance, 60-584, 27.5 x 2.4 inch
Tube
Dunlop valve
Additional Details
Crank Arm : Winora, forged, Aluminium
Clamping Ring : Quick release, Quick release, 34.9 mm
Dynamo : Via system battery
Carrier : Racktime, RT-336, 25 kg
Fenders : SKS, Chromoplastics
Lock : Abus, upgradable over Plus System
