Yamaha CrossCore RC Electric Bicycle

Price, features and specs

Rate Yamaha CrossCore RC:
3.7/5 (6 votes)
Yamaha CrossCore RC Price $ 3099 [Mesa, United States]

The given price can change depending on the colour, accessories and other features.

Country, City Showroom Price On Road Price
United States, Mesa $ 3099 --
Features
- Computer control functions include : (4) Power-level control switch, stop watch, distance units, power-level LED on/off, Bluetooth connectivity, USB power, USB connectivity, cycling function display items, time adjustment, LED headlamp power on/off, 3-color LED power assist level light indicator
- Cycling function display include : speed, average speed, maximum speed, trip distance, odometer, cadence, battery capacity (%)
- Integrated Speed Sensor
- Easy Accessory Compatibility
- ALL-NEW PWSeriesST
- Large Volume Road and City Tires
Similar Bicycles
Colours

Urban Sage
Painted Desert
Silver White

Technical Specifications
Vehicle TypeBicycle
FuelElectric
Maximum PowerRated power : 250W (Nominal), 500W (Max)
Maximum Torque70 Nm
Top Speed45 kmph
Riding ModesSupport modes : AUTO, ECO+, ECO, STANDARD, HIGH
StemYamaha Alloy 4-bolt faceplate
31.8 diameter
80 mm length (53cm, 55cm)
100 mm length (58cm)
HandlebarAlloy flat bar zero degree rise
31.8 mm diameter
640 mm width
ForkSR Suntour NEX E25. 63 mm Travel
2 x 100 mm Thru-Axle
SeatpostAlloy 30.9 x 295 mm (S), 345 mm (M L) with 2-bolt adjustable tilt saddle rail clamp
Seatpost Collar : Alloy 2-bolt 35.0 mm
GripTwo-tone ergonomic locking
ChainKMC e11 118 links
ShiftersShimano M2010 9-speed
Gear selection window
SaddleYamaha Urban Comfort Cro-Mo Rail
HeadsetIntegrated headset with 30mm headset spacers
Derailleur : FrontShimano Sora (2 x 9) Braze-on
Derailleur : RearShimano M3100 SGS
Hub : Front12 x 100 mm Quick-Release Thru-Axle (QRTA)
Hub : Rear12 x 142 mm QRTA with integrated speed sensor
SpokeSUS304 14G
CassetteSHIMANO HG400 9-speed
11-13-15-17-20-23-26-30-36T
ChainringsSAMOX 44t
StandKickstand
Motor Details
PWSeries ST
3-bolt Mount
Square taper spindle
Quad Sensor System with rear hub speed sensor
Weight: 7.71lb
Max cadence support: 110rpm
Charging Time
4-hour charge time
Display
Self-diagnosis display
Electricals
BatteryYamaha Lithium Ion with charge-life indicator and self-diagnosis display
Side-exiting dock station with anti-vibration mounting plate
Weight 6.61lb
500Wh 36V
Warranty for Battery3-Year on Frame, Drive Unit, Battery
Head LampLED
Brakes
Front BrakeShimano MT200, Shimano SM RT21, 180 mm
Rear BrakeShimano MT200, Shimano SM RT21, 160 mm
Chassis and Suspension
FrameYamaha Hydroformed Aluminum
Integrated battery
Water bottle boss
Tapered Headtube
Internal shift/brake hose routing
Rack/Fender compatible
Tyres
Wheels / Rim275” 32-Hole Dual Channel Welded Pin w/ Eyeleted Spoke
Front TyreCST C1996 27.5 x 2.0”
Rear TyreCST C1996 27.5 x 2.0”
TubeCST C1996 27.5 x 2.0”
Dimensions
Weight52.6 kg
Accessories
Yamaha battery charger
Bell
Additional Details
Sizes : 54cm (S), 57cm (M), 60cm (L)
Crank Arm : Square taper, 165mm (S), 170mm (M L)
Spoke Nipples : Brass
