Yamaha YDX-Moro 05

Price, review, features and specs

Launched globally in October 2022.

Yamaha has launched the brand-new YDX - Moro 05 Electric Mountain Bike. According to the company, it offers higher component technology and range efficiency. Also it comes with the Bump osmosis technology.

Rate Yamaha YDX-Moro 05:
3.8/5 (6 votes)
Add To Compare
Write a Review
Yamaha YDX-Moro 05 Price $ 5799 [New York, United States]

The given price can change depending on the colour, accessories and other features.

Country, City Showroom Price On Road Price
United States, New York $ 5799 --
Buy new Yamaha YDX-Moro 05

Book a Test Drive through Bikes4Sale and we will try to get you the best offer for Yamaha YDX-Moro 05.

For Exciting Offers, Book a Test Drive
By submitting, you agree to our Terms & Conditions.
303
Features
- Bump osmosis technology
- All- New Yamaha PW-X3
- Clean lines for those dirty trails
- All-New YAMAHA Interface X control switch
Colours

Forest Green

Technical Specifications
Vehicle TypeBicycle
FuelElectric
Maximum Torque85Nm
Top Speed32 kmph
Riding ModesECO, Standard, High, MTB, Extra-Power, Automatic, Walk Assist
StemAlloy 4-both faceplate
35.0 diameter
40mm length
HandlebarAlloy
35.0 diameter
780mm width
30mm rise
ForkROCKSHOX REVELATION RC
160mm TRAVEL
35mm Stanchion eMTB rated Motion Control damping with low-speed compression adjustment DebonAir air spring
SeatpostANZX 30.9 dia.
TRAVEL (S) 125mm (M) 150mm (L) 170mm
GripVELO Single Ring Locking
ChainKMC eTURBO EPT 122 links
ShiftersShimano DEORE SL-M6100-R
SaddleYAMAHA anti-slip finish with hand rail tail
HeadsetIntegrated 1 1/8"
Derailleur : RearShimano DEORE RD-M6100-SGS
Hub : FrontAnodized Alloy
Centerlock brake mount
15x110mm BOOST+ (front)
12x148mm MicroSpline freehub Quick Release Thru Axle Type
Spoke14g alloy SUS304
CassetteShimano SLX CS-M7100-12
12-spd
(10-51T)
Motor Details
YAMAHA PW-X3 Class 1 Labeled Centermount ISIS SplinedCrankarm Spindle YAMAHA Quad Sensor with Automatic Support and Walk Assist Modes
Rate power: 250W (nominal), 500W(maximum)
Charging Time
1-hour 80%, 4-hour 100%
Display
YAMAHA Interface X Control functions include: 3-color LED support-mode level light indicator, (5) Support-mode control switch, plus AUTOMATIC support mode (Aqua LED indicator) and Walk Assist mode (Purple LED indicator), Bluetoothâ„¢ connectivity, 3-color LED support-mode level light indicator, LED brightness adjustability, battery capacity (4-LED capacity indicators)
Electricals
BatteryYamaha 500Wh with Charge-life indicator and Self-diagnosis display
Anti-Vibration Mounting Plate
Weight: 6.61 lbs
500Wh 36V
Warranty for Battery3-Year
Brakes
Front BrakeMAGURA MT30 , 4-PISTON
203MM CENTER LOCK ROTOR (F/R)
Rear Brake2-PISTON, 203MM CENTER LOCK ROTOR (F/R)
Brake LeverTwo-finger lever
Chassis and Suspension
FrameYAMAHA Dual Twin Frame
Tapered Headtube
Internal cable/housing routing
2-bolt drive unit mount
12x148 rear axle spacing
Integrated YAMAHA speed sensor harness
Tyres
Wheels / RimYAMAHA 27.5+ Alloy
Tubeless tape installed
Width: 46mm (outside) 40mm (inside)
Front TyreMAXXIS 27.5X2.6
MINION DHF
Rear TyreMAXXIS 27.5X2.6
REKON
Dimensions
Length x Width x Height-- x -- x -- mm
Accessories
Protective motor and battery covers
ISCG05 chainguuide
Safety bell VP Acrylic pedals
(No Keys)
Additional Details
Size: Small, Medium, Large
Rearshock: ROCKSHOX DELUXE SELECT +150mm travel,210X55mm DebonAir+ air spring with 15 clicks of rebound adjustment 2-position compression adjustment
Seatpost Collar: Single-bolt 35.0mm
Axle: MAXLE 15MM X 110MM BOOST THRU AXLE
Crankarm: PRAXIS E-CRANK ARM 165mm LENGTH
Chainrings: PRAXIS 36T
Vehicle Warranty
3-Year on Frame, Motor
